Содержание Other: DOOSAN-DAEWOO DX140W(DX140W)
TIMING SYSTEM(019 : 019)
Номер на схеме Каталожный номер Название Количество Детали
? 65.04101-0065B VALVE;INTAKE 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SOUPAPE D'ADMISSION
LNKOP:
IP:
? 65.04101-0066B VALVE;EXHAUST 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VANNE
LNKOP:
IP:
? 65.04102-0024 SPRING;VALVE 24
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESSORT
LNKOP:
IP:
? 65.04103-0018 PLATE;VALVE SPRING 24
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PLAQUE
LNKOP:
IP:
? 65.90701-0098 WASHER 24
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? 65.04104-0009 COTTER;VALVE 48
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CLAVETTE DE VANNE
LNKOP:
IP:
? 65.04902-0016 SEAL;VALVE STEM 24
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT
LNKOP:
IP:
? 65.04130-0009A CALIPER;INTAKE 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ETRIER
LNKOP:
IP:
? 65.04130-0011 CALIPER;EXHAUST 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ETRIER
LNKOP:
IP:
? 65.04200-6038B ROCKER ARM S/F ASS'Y 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BRAS DE CULBUTEUR
LNKOP:
IP:
? 65.04201-5042B . ROCKER ARM;INTAKE 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BRAS DE CULBUTEUR
LNKOP:
IP:
? 65.04201-5043B . ROCKER ARM;EXHAUST 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BRAS DE CULBUTEUR
LNKOP:
IP:
? 65.04203-5020A . SHAFT;ROCKER ARM 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . ARBRE
LNKOP:
IP:
? 65.04202-0033 . BRACKET;ROCKER ARM 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . SUPPORT
LNKOP:
IP:
? 65.04202-0034 . BRACKET;ROCKER ARM 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . SUPPORT
LNKOP:
IP:
? 65.04202-0035 . BRACKET;ROCKER ARM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . SUPPORT
LNKOP:
IP:
? 65.97601-0124 . SPRING;COMPESSION 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . RESSORT
LNKOP:
IP:
? 65.90701-0136B . WASHER 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . RONDELLE
LNKOP:
IP:
? 06.29010-0120 . RING;SNAP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BAGUE D'ARRET
LNKOP:
IP:
? 65.90030-0018 . BOLT;SOCKET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BOULON A 6 PANS CREUX
LNKOP:
IP:
? 06.16110-0106 . WASHER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . RONDELLE
LNKOP:
IP:
? 65.04205-0014 . SCREW;ADJUST 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . VIS
LNKOP:
IP:
? 65.90501-0003 . NUT 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . ECROU
LNKOP:
IP:
? 65.04209-0005 . CAP;INTAKE 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . CHAPEAU
LNKOP:
IP:
? 65.04209-0006 . CAP;EXHAUST 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . CHAPEAU
LNKOP:
IP:
? 65.90020-0120 . BOLT;COLLARED HEX. 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BOULON
LNKOP:
IP:
? 65.04301-5003B TAPPET;VALVE 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TRINGLERIE
LNKOP:
IP:
? 65.04302-5015 ROD;PUSH 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TIGE
LNKOP:
IP:
? 65.04401-0045A CAMSHAFT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARBRE A CAMES
LNKOP:
IP:
? 06.22022-1016 DOWEL PIN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUPILLE D'AJUSTAGE
LNKOP:
IP:
? 65.90720-0032 WASHER;THRUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE DE BUTEE
LNKOP:
IP:
? 06.01913-2911 BOLT ASS'Y M6X16 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:
? 65.04501-0017 GEAR;CAM SHAFT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PIGNON
LNKOP:
IP:
? 65.90020-0117 BOLT;COLLARED HEX. 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:
? 65.04505-5018 GEAR;IDLE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PIGNON
LNKOP:
IP:
? 65.04506-0016 PIN;IDLE GEAR 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUPILLE
LNKOP:
IP:
? 65.90720-0034B WASHER;THRUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE DE BUTEE
LNKOP:
IP:
? 65.90020-0118 BOLT;COLLARED HEX. 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:
? 65.11301-5002 GEAR;DRIVE;INJECTION 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PIGNON
LNKOP:
IP:
? 65.04506-0015 PIN;IDLE GEAR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUPILLE
LNKOP:
IP:
? 65.90720-0033A WASHER;THRUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE DE BUTEE
LNKOP:
IP:
? 65.90020-0118 BOLT;COLLARED HEX. 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:
? 65.90020-0119 BOLT;COLLARED HEX. 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:

Other: DOOSAN-DAEWOO / DX140W(DX140W) / TIMING SYSTEM(019 : 019)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
