Содержание Other: DOOSAN-DAEWOO DX180LC(DX180LC)
ARTI BOOM CYLINDER - LOCK VALVE(4380 : 4380)
Номер на схеме Каталожный номер Название Количество Детали
? K1017667 CYLINDER;ARTI BOOM 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CYLINDRE
LNKOP:
IP:
? K9004433 TUBE ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU FLEXIBLE
LNKOP:
IP:
? K1000732 BUSH 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? K9004434 ROD ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE TIGE
LNKOP:
IP:
? K1000732 BUSH 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: DOUILLE
LNKOP:
IP:
? K9004435 COVER;ROD 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? 110-00110 DD-BUSH 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUSSINET
LNKOP:
IP:
? 115-00051 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE D'ARRET
LNKOP:
IP:
? 1.180-00659 SEAL;BUFFER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: ETANCHEITE
LNKOP:
IP:
? 1.180-00660 U-PACKING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT EN U
LNKOP:
IP:
? K9001146 RING;BACK UP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE
LNKOP:
IP:
? 115-00099 WIPER;DUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: RACCORD ADAPTATEUR
LNKOP:
IP:
? 115-00092 RING;RETAINING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE D'ARRET
LNKOP:
IP:
? S8011501-90 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? K9002098 RING;BACK UP 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE
LNKOP:
IP:
? 2180-1216D149 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? K9004436 PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: PISTON
LNKOP:
IP:
? 1.180-00572 SEAL;SLIPPER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT
LNKOP:
IP:
? 1.180-00433 RING;WEAR 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE D'USURE
LNKOP:
IP:
? K9002174 RING;DUST 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE
LNKOP:
IP:
? S8010801 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: JOINT TORIQUE
LNKOP:
IP:
? K9001895 RING;BACK UP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: K
desc: BAGUE
LNKOP:
IP:
? 121-00044 NUT;PISTON 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ECROU
LNKOP:
IP:
? S3523836 SCREW;SET 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? S2224971 BOLT;SOCKET 12
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:
? K9004437 PIPE BAND ASS'Y 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE DE BANDE DE TUYAU
LNKOP:
IP:
? 1.124-00104 BAND;PIPE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ATTACHE
LNKOP:
IP:
? S5100603 WASHER;SPRING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S0558153 BOLT;HEX 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? K9004462 PIPE ASS'Y-H 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE DE TUYAU
LNKOP:
IP:
? K9004193 SPACER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE D'ECARTEMENT
LNKOP:
IP:
? S8000281 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? K9004439 PIPE ASS'Y-R 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENSEMBLE DE TUYAU
LNKOP:
IP:
? S8000281 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? S5100603 WASHER;SPRING 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S2212761 BOLT;SOCKET 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON
LNKOP:
IP:
? K9003968 CLAMP;PIPE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:
? S5100703 WASHER;SPRING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? S2215761 BOLT;HEX 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S6710032 NIPPLE;GREASE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GRAISSEUR
LNKOP:
IP:
? K9004440 SEAL KIT 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: KIT D'ETANCHEITE
LNKOP:
IP:

Other: DOOSAN-DAEWOO / DX180LC(DX180LC) / ARTI BOOM CYLINDER - LOCK VALVE(4380 : 4380)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
