Содержание Other: DOOSAN-DAEWOO DX190W(DX190W)
FUEL TANK(1190 : 1190)
Номер на схеме Каталожный номер Название Количество Детали
? K1014347E FUEL TANK ASS'Y A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: RESERVOIR A GAZOLE
LNKOP:
IP:
? K1014346C TANK;FUEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RESERVOIR DE CARBURANT
LNKOP:
IP:
? 547-00026 SENDER;FUEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SIEGE
LNKOP:
IP:
? 471-00105A FILTER;FUEL STRAINER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: FILTRE
LNKOP:
IP:
? 119-00014AD1 GAUGE;LEVEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: INDICATEUR DE NIVEAU
LNKOP:
IP:
? K1001029 BOLT 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? DS2802021 CLIP 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CLIP
LNKOP:
IP:
? 473-00033 COVER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COUVERCLE
LNKOP:
IP:
? S8011450 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? S0512066 BOLT 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5102603 WASHER;SPRING 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? 186-00017A COCK;DRAIN 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ROBINET DE PURGE
LNKOP:
IP:
? S0565466 BOLT 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? 114-00425 SPACER 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BAGUE D'ECARTEMENT
LNKOP:
IP:
? 2114-1813 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENTERTOISE
LNKOP:
IP:
? 2114-1814 SHIM 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENTERTOISE
LNKOP:
IP:
? 2181-1890D2 PLUG 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? S8000111 O-RING 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:
? K1004266 CAP;FUEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CHAPEAU
LNKOP:
IP:
? S3450833 BOLT M5X0.8X12 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOULON A 6 PANS
LNKOP:
IP:
? S5100203 WASHER;SPRING 6
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE ELASTIQUE
LNKOP:
IP:
? 2195-3500 BRACKET;HOUSING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: SUPPORT
LNKOP:
IP:
? DS2105053 HOSE;FUEL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: TUYAU A GAZOLE
LNKOP:
IP:
? S8450012 CLAMP;HOSE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: COLLIER
LNKOP:
IP:
? 2181-1950D7 PLUG 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BOUCHON
LNKOP:
IP:
? S8000181 O-RING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT TORIQUE
LNKOP:
IP:

Other: DOOSAN-DAEWOO / DX190W(DX190W) / FUEL TANK(1190 : 1190)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
