| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | K1030342 | BREAKER FILTER PIPING | A/R | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: TUYAUTERIE FILTRE DE BRISEUR LNKOP: IP: |
|||
| ? | DS2023330 | HOSE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU FLEXIBLE LNKOP: IP: |
|||
| ? | DS20131074 | HOSE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU FLEXIBLE LNKOP: IP: |
|||
| ? | 471-00114 | BREAKER FILTER ASS'Y | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: FILTRE DE BRISEUR LNKOP: IP: |
|||
| ? | 474-00046 | . ELEMENT;BREAKER FILTER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . ELEMENT LNKOP: IP: |
|||
| ? | K1024909 | BRACKET | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: SUPPORT LNKOP: IP: |
|||
| ? | 2181-2815D1 | ELBOW | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COUDE LNKOP: IP: |
|||
| ? | DS2232133 | ADAPTER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: ADAPTEUR LNKOP: IP: |
|||
| ? | DS0025021 | BOLT;SET | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON LNKOP: IP: |
|||
| ? | DS0025018 | BOLT;SET | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON LNKOP: IP: |
|||
| ? | S8030161 | O-RING | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT TORIQUE LNKOP: IP: |
|||
| ? | S8000291 | O-RING | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT TORIQUE LNKOP: IP: |
