| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | K1016086A | GEAR PUMP ASS'Y | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: POMPE DE PIGNON LNKOP: IP: |
|||
| ? | - | BODY | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: CARROSSERIE LNKOP: IP: |
|||
| ? | - | COVER;FRONT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: COUVERCLE LNKOP: IP: |
|||
| ? | - | COVER;REAR | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: COUVERCLE LNKOP: IP: |
|||
| ? | - | PLATE;THRUST | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: PLAQUE LNKOP: IP: |
|||
| ? | - | SHAFT;DRIVE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: ARBRE LNKOP: IP: |
|||
| ? | - | GEAR;DRIVEN | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: PIGNON LNKOP: IP: |
|||
| ? | S2213671 | BOLT;SOCKET | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOULON LNKOP: IP: |
|||
| ? | - | NUT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: ECROU 6 PANS LNKOP: IP: |
|||
| ? | - | WASHER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: CALE LNKOP: IP: |
|||
| ? | S5102603 | WASHER | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: CALE LNKOP: IP: |
|||
| ? | - | SEAL | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: K desc: JOINT LNKOP: IP: |
|||
| ? | - | SEAL;STANDARD | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: K desc: JOINT LNKOP: IP: |
|||
| ? | - | SEAL;SQUARE SECTION | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: K desc: JOINT LNKOP: IP: |
|||
| ? | - | SEAL;SHAFT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: K desc: JOINT LNKOP: IP: |
|||
| ? | - | RING | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: ANNEAU LNKOP: IP: |
|||
| ? | - | RING;BACK-UP | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: K desc: BAGUE D'ETANCHEITE LNKOP: IP: |
|||
| ? | - | KEY | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: CLE LNKOP: IP: |
|||
| ? | - | PIN;DOWEL | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: GOUJON LNKOP: IP: |
|||
| ? | K9004282 | SEAL KIT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: POMPE DE PIGNON LNKOP: IP: |
