| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | K1019157 | BREATHER ASS'Y | A/R | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: GOUJON PRISONNIER M14X1.5X35 LNKOP: IP: |
|||
| ? | K1019158 | COVER;BREATHER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COUVERCLE LNKOP: IP: |
|||
| ? | K1019159 | VALVE;PRESSURE RELIEF | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: DECOMPRESSION LNKOP: IP: |
|||
| ? | K1019160 | GASKET;BREATHER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT LNKOP: IP: |
|||
| ? | K1019161 | PLATE;VALVE GASKET | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: PLAQUE LNKOP: IP: |
|||
| ? | K1019162 | HOSE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU FLEXIBLE LNKOP: IP: |
|||
| ? | K1019163 | CLAMP | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: COLLIER LNKOP: IP: |
|||
| ? | K1019164 | SCREW | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019165 | SEAL;O-RING | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT LNKOP: IP: |
|||
| ? | K1019166 | TUBE;BREATHER | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUBE LNKOP: IP: |
|||
| ? | K1019167 | BAFFLE;BREATHER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: DEFLECTEUR LNKOP: IP: |
