Содержание Other: DOOSAN-DAEWOO 430 PLUS(430PLUS)
CYLINDER BLOCK(002 : 002)
Номер на схеме Каталожный номер Название Количество Детали
? K1022369 CYLINDER BLOCK A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: BLOC CYLINDRE
LNKOP:
IP:
? K1022370 BLOCK;CYLINDER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: BLOC;CYLINDRES
LNKOP:
IP:
? K1022371 . BLOCK;CYLINDER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: . BLOC
LNKOP:
IP:
? K1022372 .. BLOCK;CYLINDER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: .. BLOC
LNKOP:
IP:
? K1019139 .. CAP;MAIN BEARING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: .. ROULEMENT CAP
LNKOP:
IP:
? K1019140 .. CAP;MAIN BEARING 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: .. ROULEMENT CAP
LNKOP:
IP:
? K1019141 .. SCREW;HEX FLANGE HEAD CAP 10
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. VIS
LNKOP:
IP:
? K1019142 .. PLUG;EXPANSION 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1019143 .. PLUG;THREADED 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1019144 . PIN;ROLL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . GOUPILLE
LNKOP:
IP:
? K1019145 . PLUG;EXPANSION 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . PRISE D'EXPANSION
LNKOP:
IP:
? K1019146 . PLUG;EXPANSION 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . PRISE D'EXPANSION
LNKOP:
IP:
? K1019147 . PLUG;PIPE 3
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . PRISE
LNKOP:
IP:
? K1019148 . BUSHING 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . MANCHON
LNKOP:
IP:
? K1019149 . PLUG;PIPE 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . PRISE
LNKOP:
IP:
? K1022373 . LINER;CYLINDER 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . CHEMISE DE CYLINDRE
LNKOP:
IP:
? K1019151 . PIN;GUIDE 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . GOUPILLE
LNKOP:
IP:
? K1019152 SCREW 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? K1019153 WASHER 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: RONDELLE
LNKOP:
IP:
? K1019154 SHAFT;IDLER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ARBRE
LNKOP:
IP:
? K1019155 GEAR;IDLER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: ENGRENAGE
LNKOP:
IP:
? K1019156 SCREW 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? K1019373 PIN;OIL 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: GOUJON
LNKOP:
IP:

Other: DOOSAN-DAEWOO / 430 PLUS(430PLUS) / CYLINDER BLOCK(002 : 002)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
