| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | K1019347 | WATER PUMP | A/R | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: ENSEMBLE POMPE A EAU LNKOP: IP: |
|||
| ? | K1019348 | KIT;WATER PUMP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: KIT DE POMPE D'EAU LNKOP: IP: |
|||
| ? | K1019349 | . PUMP;WATER | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . POMPE D'EAU LNKOP: IP: |
|||
| ? | K1019350 | . SEAL;O-RING | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . JOINT LNKOP: IP: |
|||
| ? | K1019351 | . GASKET;WATER PUMP | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: . JOINT DE POMPE A EAU(INTERIEUR) LNKOP: IP: |
|||
| ? | K1019352 | SCREW | 3 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019234 | SCREW | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019353 | PLUG;PIPE | 3 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOUCHON LNKOP: IP: |
|||
| ? | K1019354 | PLUG;PIPE | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOUCHON LNKOP: IP: |
|||
| ? | K1019345 | PIPE;WATER OUTLET | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: CONDUITE LNKOP: IP: |
|||
| ? | K1019404 | GASKET;THERMOSTAT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT LNKOP: IP: |
|||
| ? | K1019346 | SCREW | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019181 | THERMOSTAT | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: THERMOSTAT LNKOP: IP: |
