| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | K1019290 | OIL PAN | A/R | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: D desc: CARTER DE HUILE LNKOP: IP: |
|||
| ? | K1019291 | PAN;OIL | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: CARTER MOTEUR LNKOP: IP: |
|||
| ? | K1019292 | MAGNET | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: MAGNETIQU LNKOP: IP: |
|||
| ? | K1019293 | PLUG;THREADED | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: BOUCHON LNKOP: IP: |
|||
| ? | K1019233 | SEAL;RING | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RONDELLE D'ETANCHEITE LNKOP: IP: |
|||
| ? | K1019232 | SCREW | 4 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019294 | SCREW | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019295 | GASKET | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: JOINT LNKOP: IP: |
|||
| ? | K1019296 | PIPE;OIL SUCTION | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: TUYAU LNKOP: IP: |
|||
| ? | K1019297 | SCREW | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019298 | SCREW | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019299 | ADAPTER;OIL PAN | 1 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: RACCORD ADAPTATEUR LNKOP: IP: |
|||
| ? | K1019300 | SCREW | 2 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
|||
| ? | K1019301 | SCREW | 22 | SERIAL_NO: ICA: REP_PNO: REP_QTY: SC: desc: VIS LNKOP: IP: |
