Содержание Other: DOOSAN-DAEWOO 430 PLUS(430PLUS)
CYLINDER HEAD(009 : 009)
Номер на схеме Каталожный номер Название Количество Детали
? K1022389 CYLINDER HEAD A/R
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: CULASSE
LNKOP:
IP:
? K1022390 CYLINDER HEAD ASSY 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CULLASSE
LNKOP:
IP:
? K1019240 . VALVE;INTAKE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . VALVE DE PRISE
LNKOP:
IP:
? K1019241 . VALVE;EXHAUST 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . SOUPAPE D'ECHAPPEMENT
LNKOP:
IP:
? K1019242 . PIN;ROLL 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . GOUPILLE
LNKOP:
IP:
? K1019243 . SEAL;VALVE STEM 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . JOINT
LNKOP:
IP:
? K1019244 . SPRING;VALVE 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . JOINT TORIQUE
LNKOP:
IP:
? K1019245 . RETAINER;VALVE SPRING 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . ARRETOIR
LNKOP:
IP:
? K1019246 . COLLET;VALVE 16
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: . BAGUE
LNKOP:
IP:
? K1022391 . HEAD;CYLINDER 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: . CULASSE
LNKOP:
IP:
? K1019147 .. PLUG;PIPE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1019248 .. PLUG;EXPANSION 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1019249 .. GUIDE;VALVE STEM 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. GUIDE
LNKOP:
IP:
? K1019250 .. GUIDE;VALVE STEM 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. GUIDE
LNKOP:
IP:
? K1019251 .. SEAT;ENGINE INTAKE VALVE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. SIEGE DE VALVE
LNKOP:
IP:
? K1019252 .. SEAT;ENGINE EXHAUST VALVE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. SIEGE DE VALVE
LNKOP:
IP:
? K1019253 .. PLUG;EXPANSION 2
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1019149 .. PLUG;PIPE 5
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1019255 .. PLUG;DRIVE 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: .. PRISE
LNKOP:
IP:
? K1022378 .. CHAMBER;INJECTION 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC: D
desc: .. CHAMBRE
LNKOP:
IP:
? K1019256 GASKET;CYLINDER HEAD 1
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: JOINT DE CULASSE
LNKOP:
IP:
? K1019257 SCREW 14
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? K1019258 SCREW 4
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: VIS
LNKOP:
IP:
? K1019259 CAP;VALVE 8
SERIAL_NO:
ICA:
REP_PNO:
REP_QTY:
SC:
desc: CAPUCHON
LNKOP:
IP:

Other: DOOSAN-DAEWOO / 430 PLUS(430PLUS) / CYLINDER HEAD(009 : 009)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
