| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 706 173 C92 | FRAME ASSY, REAR MAIN | 1 | F1 | |||
| ? | (NSS) | • FRAME, REAR MAIN | 1 | ||||
| ? | 621 546 C1 | • DOWEL, SHOE | 8 | ||||
| ? | 621 547 C1 | • DOWEL, FINAL DRIVE | 4 | ||||
| ? | 621 090 C91 | • BEARING, NEEDLE | 4 | ||||
| ? | 613 908 C1 | • PLUG, PIPE | 4 | ||||
| ? | 271 647 R1 | • PLUG, DRAIN | 1 | ||||
| ? | 601 093 C1 | • PLUG, CUP | 2 | ||||
| ? | 652 817 C1 | • TUBE, BRAKE ROD | 1 | ||||
| ? | 621 549 C1 | • INSERT, ADJUSTING BOLT | 2 | ||||
| ? | 104 942 | • PLUG, CORK - #6 | A/R | ||||
| ? | 117 926 | • PLUG, CORK - #12 | A/R | ||||
| ? | 23 624 R1 | • PLUG, CUP | 4 | ||||
| ? | |||||||
| ? | F1 - SERVICE PART WILL BE AVAILABLE ON SPECIAL ORDER WITH THE CLEARANCE | ||||||
| ? | OF THE ENGINEERING DEPARTMENT. PRODUCT IDENTIFICATION NUMBER (PIN) | ||||||
| ? | MUST BE FURNISHED WHEN ORDERING. ORDER ON MACHINE ORDER FORM. |
