| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1308 327 H91) | STEERING CYLINDER CONNECTIONS | -54 | F1 | |||
| ? | 690 693 R1 | • PIN, SPRING - 1/2x1 | 2 | ||||
| ? | 9410 229 | • CONNECTOR, LONG | 4 | ||||
| ? | 570 828 R1 | • RING, SEAL | 4 | ||||
| ? | 628 095 C1 | • FLANGE, SEAL | 5 | ||||
| ? | 25 534 R1 | • WASHER, FLAT - 3/8 | 10 | ||||
| ? | 9413 979 | • NUT, LOCK - 3/8NC | 10 | ||||
| ? | 652 341 C1 | • BOOT, CONNECTOR | 5 | F2 | |||
| ? | 112 700 R1 | • CLAMP, BOOT | 5 | F2 | |||
| ? | • CYLINDER, STEERING (SEE PG 07-090) | -29 | 07ZZTD9H.002 | ||||
| ? | 24 861 R1 | • BOLT, HEX - 1/2NCx1-1/4 | 4 | ||||
| ? | 25 536 R1 | • WASHER, FLAT - 1/2 | 4 | ||||
| ? | • CYLINDER, BRAKE (SEE PG 04-020) | -29 | 04ZZD32E.001 | ||||
| ? | 24 866 R1 | • BOLT, HEX - 1/2NCx2-1/2 | 2 | ||||
| ? | 24 861 R1 | • BOLT, HEX - 1/2NCx1-1/4 | 2 | ||||
| ? | 25 546 R1 | • WASHER, FLAT - 1/2 | 4 | ||||
| ? | 1306 573 H1 | • CONNECTOR, LONG | 1 | ||||
| ? | 369 751 R1 | • RING, SEAL | 1 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - QT. 4 ARE PART OF CYLINDER SEAL PACKAGE 679 248 C91. | ||||||
| ? |
