| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (1278 275 H91) | CONVERTER ASSY | -54 | F1 | |||
| ? | 637 983 C1 | • HOUSING, DRIVE | 1 | ||||
| ? | 606 265 C91 | • BEARING, BALL | 1 | ||||
| ? | 926 906 C1 | • IMPELLER ASSY | 1 | ||||
| ? | (NSS) | • • IMPELLER | 1 | ||||
| ? | 630 411 C1 | • • SLEEVE, OIL SEAL | 1 | ||||
| ? | 27 347 R1 | • BOLT, HEX - 3/8NCx1-1/8 | 12 | ||||
| ? | 631 944 C1 | • WASHER, FLAT | 12 | ||||
| ? | 625 885 C91 | • BEARING, NEEDLE | 1 | ||||
| ? | 926 903 C1 | • TURBINE | 1 | ||||
| ? | 1278 271 H1 | • STATOR | 1 | ||||
| ? | 619 893 C1 | • WASHER, THRUST | 2 | ||||
| ? | 625 060 C91 | • BEARING, THRUST | 2 | ||||
| ? | 374 041 R1 | • WASHER, THRUST | 2 | ||||
| ? | 627 193 C1 | • RING, SEAL | 1 | F2 | |||
| ? | 1245 942 H1 | • PLATE, FLEX | 1 | ||||
| ? | 619 951 C1 | • PLATE, LOCK | 1 | ||||
| ? | 25 769 R1 | • BOLT, HEX - 3/8NFx5/8 | 6 | ||||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. | ||||||
| ? | |||||||
| ? | |||||||
| ? | F2 - PART OF TORQUE CONVERTER SEAL KIT 625 879 C93. | ||||||
| ? |
