| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 710 741 C2 | HOSE, CONVERTER INLET | 1 | ||||
| ? | 656 528 C1 | ELBOW, 90° | 1 | ||||
| ? | 368 269 R1 | RING, SEAL | 1 | ||||
| ? | SENDER, TEMPERATURE (SEE PG 08-002) | -29 | 08ADD32E.002 | ||||
| ? | 9410 979 | ELBOW, 90° | 4 | ||||
| ? | 368 269 R1 | RING, SEAL | 4 | ||||
| ? | 1282 836 H1 | TUBE, ADAPTER | 1 | ||||
| ? | 1214 175 H1 | HOSE, COOLER INLET | 1 | ||||
| ? | 1201 626 C1 | HOSE, COOLER OUTLET | 1 | ||||
| ? | 9410 205 | CONNECTOR | 1 | ||||
| ? | 368 269 R1 | RING, SEAL | 1 | ||||
| ? | 336 627 R91 | HOSE, CONVERTER DRAIN | 1 | ||||
| ? | 736 983 C1 | HOSE, CHAFING | 1 | ||||
| ? | 306 132 C2 | STRAP, TIE | 2 | ||||
| ? | 317 262 R1 | CLAMP, HOSE | 1 | ||||
| ? | 24 839 R1 | BOLT, HEX - 3/8NCx3/4 | 1 | ||||
| ? | 25 534 R1 | WASHER, FLAT - 3/8 | 1 | ||||
| ? | ELBOW, LUBE INLET (SEE PG 07-060) | -29 | 07CRD32E.002 | ||||
| ? | CONNECTOR, C PORT REG VALVE (SEE PG 07-060) | -29 | 07CRD32E.002 | ||||
| ? | 306 132 C2 | STRAP, TIE | A/R |
