| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1306 951 H91 | PAD ASSEMBLY, BRAKE | 1 | SN: P096338- |
|||
| ? | 1306 952 H91 | • BELLCRANK ASSEMBLY, FINAL | 1 | SN: P096338- |
|||
| ? | 1306 953 H91 | • • BELLCRANK, FINAL | 1 | SN: P096338- |
|||
| ? | 1271 230 H1 | • • BEARING, NEEDLE | 2 | SN: P096338- |
|||
| ? | 109 454 | • • FITTING, LUBE | 1 | SN: P096338- |
|||
| ? | 1258 301 H91 | • BRACKET, MOUNTING | 1 | SN: P096338- |
|||
| ? | 1258 303 H91 | • PAWL, BRAKE | 1 | SN: P096338- |
|||
| ? | 25 883 R1 | • WASHER, FLAT - 1-5/16 | 1 | SN: P096338- |
|||
| ? | 933 075 R1 | • RING, RETAINING | 1 | SN: P096338- |
|||
| ? | 355 476 R1 | • WASHER, FLAT | 1 | SN: P096338- |
|||
| ? | 269 192 R1 | • RING, RETAINING | 2 | SN: P096338- |
|||
| ? | 1258 297 H91 | • ROD, RELEASE | 1 | SN: P096338- |
|||
| ? | 331 150 R1 | • SPACER, SPRING | 1 | SN: P096338- |
|||
| ? | 364 437 R1 | • PIN, ROLL - 3/16x7/8 | 1 | SN: P096338- |
|||
| ? | 666 020 C2 | • SPRING, TENSION | 1 | SN: P096338- |
