| Наименование | Страница | Код страницы |
|---|---|---|
| FIG. B0000-01A1 THROTTLE LINKS | B-004 | B0000-01A1 |
| FIG. B0000-01A1 THROTTLE LINKS | B-004 | B0000-01A1 |
| FIG. B0000-01A2 DECELERATOR OVER TRAVEL | B-006 | B0000-01A2 |
| FIG. B0000-01A3 OVER TRAVEL THROTTLE | B-008 | B0000-01A3 |
| FIG. F2300-02A2 BRAKE SUPPORT BRACKET | F-010 | F2300-02A2 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1311 319 H91 | ENGINE CONTROLS | 1 | SN: P096338- |
F1 | ||
| ? | 104 038 | • CLEVIS, ROD END | 1 | SN: P096338- |
|||
| ? | 25 487 R1 | • BOLT, HEX - 1/4NCx1-1/2 | 1 | SN: P096338- |
|||
| ? | 25 532 R1 | • WASHER, FLAT - 1/4 | 4 | SN: P096338- |
|||
| ? | 26 110 R1 | • NUT, LOCK - 1/4NC | 1 | SN: P096338- |
|||
| ? | 1279 059 H1 | • CLAMP, SPACER | 2 | SN: P096338- |
|||
| ? | 104 036 | • CLEVIS, ROD END | 1 | SN: P096338- |
|||
| ? | 28 232 R1 | • SCREW, SET - 1/4NF | 1 | SN: P096338- |
|||
| ? | 20 791 R1 | • PIN, CLEVIS | 1 | SN: P096338- |
|||
| ? | 103 361 | • PIN, COTTER | 1 | SN: P096338- |
|||
| ? | 1280 178 H1 | • CONNECTOR, REDUCER | 1 | SN: P096338- |
|||
| ? | 1309 771 H1 | • ROD, PUMP CONTROL | 1 | SN: P096338- |
|||
| ? | 25 523 R1 | • NUT, CONNECTOR - 3/8NF | 2 | SN: P096338- |
|||
| ? | 114-43-48220 | • LEVER, CONTROL | 1 | SN: P096338- |
|||
| ? | 203-43-44360 | • KNOB, CONTROL LEVER | 1 | SN: P096338- |
|||
| ? | 1281 116 H1 | • SHAFT, THROTTLE | 1 | SN: P096338- |
|||
| ? | 114-43-48381 | • GROMMET | 1 | SN: P096338- |
|||
| ? | 740 528 C1 | • BOLT, ADJUSTING | 2 | SN: P096338- |
|||
| ? | 25 522 R1 | • NUT, HEX - 3/6NC | 2 | SN: P096338- |
|||
| ? | 16 617 R1 | • PIN, CLEVIS - 3/8x1-1/6 | 1 | SN: P096338- |
|||
| ? | 103 373 | • PIN, COTTER - 3/32x3/4 | 1 | SN: P096338- |
|||
| ? | 16 617 R1 | • PIN, CLEVIS - 3/8x1-1/6 | 1 | SN: P096338- |
|||
| ? | 103 373 | • PIN, COTTER - 3/32x3/4 | 1 | SN: P096338- |
|||
| ? | 1258 327 H91 | • CABLE, THROTTLE | 1 | SN: P096338- |
|||
| ? | 26 030 R1 | • NUT, HEX - 1/4NF | 1 | SN: P096338- |
|||
| ? | 281 800 C92 | • JOINT, BALL - 1/4NF | 1 | SN: P096338- |
|||
| ? | 25 532 R1 | • WASHER, FLAT - 1/4 | 1 | SN: P096338- |
|||
| ? | 27 122 R1 | • NUT, LOCK - 1/4NF | 1 | SN: P096338- |
|||
| ? | 26 030 R1 | • NUT, HEX - 1/4NF | 1 | SN: P096338- |
|||
| ? | 1309 772 H1 | • LEVER, INJECTION PUMP | 1 | SN: P096338- |
|||
| ? | 30 192 R1 | • BOLT, MOUNTING - M6X16 | 2 | SN: P096338- |
|||
| ? | 30 209 R1 | • WASHER, FLAT - M6 | 2 | SN: P096338- |
|||
| ? | 30 270 R1 | • WASHER, LOCK - M6 | 2 | SN: P096338- |
|||
| ? | |||||||
| ? | F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS. | ||||||
| ? |
