Номер на схеме	Каталожный номер	Название	Количество	Детали
?	716 833 C94	SHAFT ASSEMBLY, DIRECTIONAL	1	SN: P096338-
?	709 601 C93	• SHAFT ASSEMBLY, INPUT	1	SN: P096338-
?	21 277 R1	• • PIN, DOWEL - 7/16x1/2	3	SN: P096338-
?	212 012 H1	• • PIN, ROLL - 5/64x3/8	1	SN: P096338-
?	28 265 R1	• • PIN, ROLL - 1/8x3/8	1	SN: P096338-
?	659 907 C1	• RACE, THRUST	8	SN: P096338-
?	374 011 R91	• BEARING, THRUST	4	SN: P096338-
?	610 766 C91	• BEARING, NEEDLE	2	SN: P096338-
?	709 789 C1	• GEAR AND HUB, FORWARD	1	SN: P096338-
?	632 341 C1	• RING, RETAINING	2	SN: P096338-
?	1212 820 C1	• RETAINER, SPRING	4	SN: P096338-
?	1212 816 C1	• SPRING, RETURN	2	SN: P096338-
?	741 778 C3	• KIT, HUB AND DRUM	1	SN: P096338-
?	366 694 C1	• RING, RETAINING	2	SN: P096338-
?	709 837 C1	• PISTON, CLUTCH	2	SN: P096338-
?	659 910 C1	• SEAL, PISTON - INNER	2	SN: P096338-	F1
?	659 913 C1	• RING, SEAL	2	SN: P096338-	F1
?	709 631 C1	• SEAL, PISTON - OUTER	2	SN: P096338-	F1
?	709 632 C1	• RING, SEAL	2	SN: P096338-	F1
?	709 777 C2	• DISC, FRICTION	12	SN: P096338-
?	716 719 C1	• PLATE, SEPARATOR	10	SN: P096338-
?	1286 827 H1	• PLATE, SUPPORT	2	SN: P096338-
?	1228 459 H2	• RING, RETAINING - CAPTURED	2	SN: P096338-
?	709 790 C1	• GEAR AND HUB, REVERSE	1	SN: P096338-
?	716 907 C1	• SPACER, BEARING	2	SN: P096338-
?
?		F1 - PART OF TRANSMISSION SERVICE KIT 741 453 C91.
?
