| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-03-52230 | HOSE, RADIATOR UPPER | 1 | ||||
| ? | 208-09-11120 | CLAMP | 2 | ||||
| ? | 208-03-52220 | HOSE, RADIATOR LOWER | 1 | ||||
| ? | 208-09-11120 | CLAMP | 2 | ||||
| ? | 207-03-31160 | CONNECTOR | 1 | ||||
| ? | 01010-81025 | BOLT | 4 | ||||
| ? | 01643-51032 | WASHER | 4 | ||||
| ? | 207-03-31271 | GASKET | 1 | ||||
| ? | 07042-30312 | PLUG | 1 | ||||
| ? | 207-03-51530 | CLIP | 1 | ||||
| ? | 01010-81230 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 1 | ||||
| ? | 20Y-06-15240 | TANK, RADIATOR OVERFLOW | 1 | ||||
| ? | 205-03-71532 | • CAP | 1 | ||||
| ? | 208-03-52350 | BRACKET | 1 | ||||
| ? | 01010-81230 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 20Y-03-11361 | BAND | 1 | ||||
| ? | 01580-10806 | NUT | 2 | ||||
| ? | 01643-30823 | WASHER | 2 | ||||
| ? | 20Y-03-11270 | HOSE | 1 | ||||
| ? | 206-03-43340 | CLIP | 2 | ||||
| ? | 206-03-43331 | HOSE | 1 | ||||
| ? | 206-03-43340 | CLIP | 1 | ||||
| ? | RADIATOR (SEE PG 01-008) | -29 | 06AHP400.001 | ||||
| ? | COVER, THERMOSTAT (SEE PG E5-006) | -29 | E5AI6125.002 | ||||
| ? | PUMP, WATER (SEE PG E5-002) | -29 | E5AC6125.002 |
