| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-54-51611 | DOOR, L.H | 1 | ||||
| ? | 208-54-51940 | • SHEET | 1 | ||||
| ? | 208-54-51631 | • SHEET | 1 | ||||
| ? | 198-54-41982 | • LOCK ASSEMBLY | 1 | ||||
| ? | 207-54-51790 | HINGE | 1 | ||||
| ? | 01010-81235 | BOLT | 4 | ||||
| ? | 01010-81225 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 8 | ||||
| ? | 20B-54-12210 | SPRING | 1 | ||||
| ? | 01220-40408 | SCREW | 2 | ||||
| ? | 01641-20405 | WASHER | 2 | ||||
| ? | 205-54-64140 | BAR | 1 | ||||
| ? | 04050-13020 | PIN, COTTER | 1 | ||||
| ? | 207-54-51391 | BRACKET | 1 | ||||
| ? | 01010-81020 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 20Y-54-12920 | CLAMP | 1 | ||||
| ? | 01010-81020 | BOLT | 2 | ||||
| ? | 01643-31032 | WASHER | 2 | ||||
| ? | 566-54-14420 | STOPPER | 2 | ||||
| ? | 203-54-52610 | PLATE | 2 | ||||
| ? | 20Y-54-11760 | SCREW | 4 | ||||
| ? | 566-54-13570 | WASHER | 4 | ||||
| ? | 01580-00806 | NUT | 4 | ||||
| ? | 01641-21016 | WASHER | 1 | ||||
| ? | FRAME (SEE PG 05-006) | -29 | 13AR6400.001 | ||||
| ? | FRAME, REVOLVING (SEE PG 04-022) | -29 | 09AHP400.001 |
