| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-54-52512 | HOOD | 1 | ||||
| ? | 205-54-75362 | • HINGE | 2 | ||||
| ? | 208-54-52151 | • SHEET | 1 | ||||
| ? | 208-54-52531 | • SHEET | 1 | ||||
| ? | 208-54-52541 | • SHEET | 1 | ||||
| ? | 208-54-52550 | • SHEET | 2 | ||||
| ? | 208-54-52560 | • SHEET | 1 | ||||
| ? | 208-54-A1220 | • SHEET | 1 | ||||
| ? | 208-54-52620 | • SHEET | 1 | ||||
| ? | 208-54-52630 | • SHEET | 1 | ||||
| ? | 208-54-52650 | • SHEET | 1 | ||||
| ? | 01010-81230 | BOLT | 6 | ||||
| ? | 175-54-34170 | WASHER | 6 | ||||
| ? | 207-54-52251 | BRACKET | 1 | ||||
| ? | 207-54-52261 | BRACKET | 1 | ||||
| ? | 01010-81250 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 208-54-52580 | SPRING | 1 | ||||
| ? | 208-54-52590 | SPRING | 1 | ||||
| ? | 208-54-52120 | STAY | 1 | ||||
| ? | 208-54-52130 | STAY | 1 | ||||
| ? | 04205-31235 | PIN | 1 | ||||
| ? | 04205-31238 | PIN | 1 | ||||
| ? | 04052-01253 | PIN | 2 | ||||
| ? | 207-54-52380 | PLATE | 1 | ||||
| ? | 20B-54-12210 | SPRING | 1 | ||||
| ? | 01220-40410 | SCREW | 2 | ||||
| ? | 01601-20410 | WASHER | 2 | ||||
| ? | 04205-31230 | PIN | 1 | ||||
| ? | 04052-01253 | PIN | 1 | ||||
| ? | 207-01-32111 | PIPE, EXHAUST | 1 | ||||
| ? | 01010-81230 | BOLT | 4 | ||||
| ? | 124-54-26540 | WASHER | 4 | ||||
| ? | FRAME (SEE PG 05-018) | -29 | 13AHP400.002 | ||||
| ? | FRAME, REVOLVING (SEE PG 04-022) | -29 | 09AHP400.001 | ||||
| ? | FRAME (SEE PG 05-018) | -29 | 13AHP400.002 |
