| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 20Y-43-16640 | COVER, CONSOLE | 1 | ||||
| ? | 20Y-43-16650 | • BUTTON ASSEMBLY, CONSOLE ADJUSTMENT | 1 | ||||
| ? | 20Y-43-16580 | • TRAY | 1 | ||||
| ? | 20Y-43-16590 | SCREW | 4 | ||||
| ? | 20Y-43-16620 | COVER | 1 | ||||
| ? | 20Y-43-16660 | COLLAR | 5 | ||||
| ? | 20Y-43-16560 | COVER | 1 | ||||
| ? | 20Y-43-16570 | REST, ARM | 1 | ||||
| ? | 01010-60850 | BOLT | 4 | ||||
| ? | 01010-60816 | BOLT | 1 | ||||
| ? | 01643-30823 | WASHER | 5 | ||||
| ? | 20Y-43-16630 | BRACKET | 1 | ||||
| ? | 20Y-43-16610 | RAIL | 1 | ||||
| ? | 01580-10806 | NUT | 6 | ||||
| ? | 01643-30823 | WASHER | 6 | ||||
| ? | 01010-60820 | BOLT | 2 | ||||
| ? | 01580-10806 | NUT | 4 | ||||
| ? | 01643-70823 | WASHER | 6 | ||||
| ? | 20Y-43-16141 | STAND | 1 | ||||
| ? | 01010-81225 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 20Y-43-16151 | COVER | 1 | F1 | |||
| ? | 01010-80820 | BOLT | 4 | ||||
| ? | 01643-30823 | WASHER | 4 | ||||
| ? | 20Y-43-16161 | COVER | 1 | F1 | |||
| ? | 01010-80820 | BOLT | 4 | ||||
| ? | 01643-30823 | WASHER | 4 | ||||
| ? | 20Y-06-16111 | PANEL | 1 | ||||
| ? | 01010-80850 | BOLT | 2 | ||||
| ? | 01010-80830 | BOLT | 2 | ||||
| ? | 01643-30823 | WASHER | 4 | ||||
| ? | 01010-80830 | BOLT | 1 | ||||
| ? | 01643-30823 | WASHER | 1 | ||||
| ? | |||||||
| ? | F1 - THIS COVER IS NOT USED ON MACHINES EQUIPPED WITH A DEFROSTER | ||||||
| ? | SEE PG 05-081 FOR THE PROPER COVER. |
