| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-32-AX110 | CHAIN ASSEMBLY, TRACK FOR 23.6 IN. SHOES | 2 | a | |||
| ? | 208-32-AX120 | CHAIN ASSEMBLY, TRACK FOR 27.5 IN. SHOES | 2 | b | |||
| ? | 208-32-AX130 | CHAIN ASSEMBLY, TRACK FOR 31.5 IN. SHOES | 2 | c | |||
| ? | 208-32-AX140 | CHAIN ASSEMBLY, TRACK FOR 35.4 IN. SHOES | 2 | d | |||
| ? | 208-32-A1121 | • CHAIN, L.H. TRACK | 104 | ||||
| ? | 208-32-A1131 | • CHAIN, R.H. TRACK | 104 | ||||
| ? | 208-32-A1140 | • BUSHING, REGULAR | 100 | ||||
| ? | 154-32-11283 | • SEAL, REGULAR W-TYPE DUST | 200 | ||||
| ? | 154-820-A153 | • PIN, REGULAR | 100 | ||||
| ? | 208-32-A1170 | • BUSHING, MASTER | 4 | ||||
| ? | 154-32-11260 | • SEAL, MASTER W-TYPE | 8 | ||||
| ? | 208-32-A1190 | • PIN, MASTER | 4 | ||||
| ? | • SHOE, TRACK (SEE PG 03-036) | -29 | 15AD6400.002 | ||||
| ? | • BOLT, TRACK SHOE (SEE PG 03-036) | -29 | 15AD6400.002 | ||||
| ? | • NUT, TRACK SHOE (SEE PG 03-036) | -29 | 15AD6400.002 | ||||
| ? | |||||||
| ? | 0.394 IN. (10 MM) OVERSIZE PARTS | ||||||
| ? | 154-98-09411 | • BUSHING, REGULAR | A/R | ||||
| ? | 154-98-09212 | • PIN, REGULAR | A/R | ||||
| ? | 154-98-09441 | • BUSHING, MASTER | A/R | ||||
| ? | 208-98-09030 | • PIN, MASTER | A/R | ||||
| ? | |||||||
| ? | 0.709 IN. (18 MM) OVERSIZE PARTS | ||||||
| ? | 154-98-09431 | • BUSHING, REGULAR | A/R | ||||
| ? | 154-98-09032 | • PIN, REGULAR | A/R | ||||
| ? | 154-98-09461 | • BUSHING, MASTER | A/R | ||||
| ? | 208-98-09040 | • PIN, MASTER | A/R |
