| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6150-23-4160 | HOUSING, FLYWHEEL | 1 | ||||
| ? | PIN, DOWEL (SEE PG E2-002) | -29 | E2AC6125.002 | ||||
| ? | 07042-00617 | PLUG | 1 | ||||
| ? | 01010-31650 | BOLT | 6 | ||||
| ? | 01010-61660 | BOLT | 2 | ||||
| ? | 01010-31050 | BOLT | 2 | ||||
| ? | 6150-23-4240 | SEAL, REAR | 1 | ||||
| ? | 6151-31-1631 | FLYWHEEL ASSEMBLY | 1 | ||||
| ? | (NSS) | • FLYWHEEL | 1 | ||||
| ? | 6150-31-1351 | • GEAR, RING - FLYWHEEL | 1 | ||||
| ? | 01050-31645 | BOLT | 6 | ||||
| ? | 01643-31645 | WASHER | 6 | ||||
| ? | 7861-92-2310 | SENSOR, TACHOMETER PICKUP | 1 | ||||
| ? | 08036-10814 | CLIP | 1 | ||||
| ? | 01435-21016 | BOLT | 1 | ||||
| ? | 09920-00150 | LIQUID GASKET | A/R | ||||
| ? | HARNESS, WIRING (SEE PG 01-052) | -29 | 08ADP400.003 |
