Найти k-part Содержание Excavators Komatsu PC400LC-5 S/N A70501-UP(PC4005KE) ELECTRICAL SYSTEM WIRING CAB TO SENSOR AND VALVE(01-054 : 08ADP400.004) Номер на схеме Каталожный номер Название Количество Детали ? 208-06-51281 WIRING HARNESS, CAB TO SENSOR AND VALVE 1 ? 22W-06-13590 • DIODE 5 ? 08036-03014 CLIP 2 ? 113-899-7950 CLIP 3 ? 01010-81225 BOLT 5 ? 01643-31232 WASHER 5 ? 08036-01214 CLIP 4 ? 01010-81225 BOLT 4 ? 01643-31232 WASHER 4 ? 08035-01514 CLIP 3 ? 01010-81225 BOLT 3 ? 01643-31232 WASHER 3 ? 208-06-51370 BRACKET 1 ? 01010-81220 BOLT 2 ? 01643-31232 WASHER 2 ? 08034-00414 BAND 2 ? 113-899-7950 CLIP 1 ? 01010-81225 BOLT 1 ? 01643-31232 WASHER 1 ? 17M-49-15260 BRACKET 1 ? 01010-81225 BOLT 1 ? 01643-31232 WASHER 1 ? SENSOR, PRESSURE (SEE PG 01-046) -29 08CDP400.001 ? SWITCH, PRESSURE (SEE PG 01-046) -29 08CDP400.001 ? VALVE, CONTROL (SEE PG 06-068) -29 10BH6400.003 ? CLAMP (SEE PG 01-056) -29 08ADP400.005 ? VALVE, SOLENOID (SEE PG 06-140) -29 10BH6300.016 ? SENSOR, HYDRAULIC OIL LEVEL (SEE PG 01-048) -29 08CD6300.001 ? PUMP, HYDRAULIC (SEE PG 06-022) -29 10AV6400.001 ? BRACKET (SEE PG 06-168) -29 10AD6300.007 ? VALVE, HIGH-LOW (SEE PG 06-014) -29 10BH6400.001 ? SWITCH, PRESSURE (SEE PG 01-046) -29 08CDP400.001 ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?
