| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | LAMP ASSEMBLY (SEE PG 01-044) | -29 | F1;08BHP300.001 | a | |||
| ? | 20Y-06-A1480 | LAMP ASSEMBLY, WORKING | 1 | F2 | b | ||
| ? | 208-06-51430 | HORN | 1 | ||||
| ? | 208-06-51440 | HORN | 1 | ||||
| ? | 01010-80825 | BOLT | 2 | ||||
| ? | 01643-30823 | WASHER | 2 | ||||
| ? | 208-06-51450 | HARNESS, HORN WIRING | 1 | ||||
| ? | 01010-80825 | BOLT | 1 | ||||
| ? | 01643-30823 | WASHER | 1 | ||||
| ? | 08088-10000 | SWITCH, BATTERY RELAY | 1 | ||||
| ? | 01010-80820 | BOLT | 2 | ||||
| ? | 01643-30823 | WASHER | 2 | ||||
| ? | 08036-00814 | CLIP | 1 | ||||
| ? | 01010-81225 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 1 | ||||
| ? | HARNESS (SEE PG 01-056) | -29 | 08ADP400.005 | ||||
| ? | 20Y-06-A1181 | BRACKET | 1 | F2 | |||
| ? | 01643-31445 | WASHER | 1 | F2 | |||
| ? | 01010-81425 | BOLT | 1 | F2 | |||
| ? | |||||||
| ? | F1 - S/N A70891 AND BELOW. FOR REPLACEMENT PARTS ORDER THE FOLLOWING: | ||||||
| ? | |||||||
| ? | 20Y-06-A1480 | LAMP ASSEMBLY | 1 | ||||
| ? | 20Y-06-A1181 | BRACKET | 1 | ||||
| ? | 01643-31445 | WASHER | 1 | ||||
| ? | 01010-81425 | BOLT | 1 | ||||
| ? | |||||||
| ? | F2 - S/N A70892 AND UP. | ||||||
| ? |
