Номер на схеме	Каталожный номер	Название	Количество
?	07102-20514	HOSE, SWIVEL JOINT TO TEE	1
?	21T-06-11950	CLIP	2
?	01010-81225	BOLT	2
?	01643-31232	WASHER	2
?	207-62-54850	TEE	1
?	07002-02434	O-RING	2
?	07236-10522	ELBOW	1
?	07102-20506	HOSE, SWING MOTOR TO ADAPTER	1
?	207-62-56160	ELBOW	1
?	07002-02434	O-RING	1
?	07102-20512	HOSE, TEE TO HYDRAULIC OIL TANK	1
?	08036-02514	CLIP	2
?	01010-81225	BOLT	2
?	01643-31232	WASHER	2
?	07235-10522	ELBOW	1
?	07002-02434	O-RING	1
?	208-62-53671	BRACKET	1
?	07283-33450	CLIP	2
?	01599-01011	NUT	4
?	01643-31032	WASHER	4
?	207-62-53830	ELBOW	1
?	07002-02434	O-RING	1
?	07102-20617	HOSE, ELBOW TO HYDRAULIC PUMP	1
?	196-916-1610	CLIP	2
?	01010-81225	BOLT	1
?	01643-31232	WASHER	1
?		VALVE, CONTROL (SEE PG 06-068)	-29	10BH6400.003
?		MOTOR, SWING (SEE PG 06-118)	-29	10AV6400.016
?		JOINT, SWIVEL (SEE PG 06-106)	-29	N1310X30.003
?		BLOCK, MAIN FILTER (SEE PG 06-164)	-29	10ADP400.003
?		HOSE (SEE PG 06-168)	-29	10AD6300.007
?		PUMP, HYDRAULIC (SEE PG 06-022)	-29	10AV6400.001
?		HOSE (SEE PG 06-126)	-29	10AK6400.001
?		ELBOW (SEE PG 06-128)	-29	10AK6300.003
?		TUBE (SEE PG 06-154)	-29	10AK6400.002
?		HOSE (SEE PG 06-160)	-29	10AD6400.004
