| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 702-16-36000 | VALVE, P.P.C. TRAVEL | 1 | ||||
| ? | (NSS) | • BODY | 1 | ||||
| ? | 07043-50312 | • PLUG | 2 | ||||
| ? | (NSS) | • VALVE | 4 | ||||
| ? | 702-16-51140 | • SHIM, .012 IN. (0.3 MM) | 8 | ||||
| ? | 702-16-51510 | • SPRING | 4 | ||||
| ? | 702-16-51920 | • SPRING | 4 | ||||
| ? | 702-16-51832 | • RETAINER | 4 | ||||
| ? | 702-16-51170 | • COLLAR | 8 | ||||
| ? | 702-16-52120 | • PISTON | 4 | ||||
| ? | 702-16-51880 | • COLLAR | 4 | ||||
| ? | 07000-02021 | • O-RING | 4 | ||||
| ? | 702-16-51270 | • SEAL | 4 | ||||
| ? | 702-16-51941 | • PLATE | 1 | ||||
| ? | 01010-80816 | • BOLT | 4 | ||||
| ? | 01643-30823 | • WASHER | 4 | ||||
| ? | 702-16-51890 | FILTER, P.P.C. VALVE FOR TRAVEL | 1 | ||||
| ? | 07002-02034 | O-RING | 1 |
