| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 09483-20450 | HOSE | 1 | ||||
| ? | 15R-911-5560 | HOSE | 1 | ||||
| ? | 09484-00450 | CONNECTOR | 2 | ||||
| ? | 09483-00460 | HOSE | 1 | ||||
| ? | 09483-00450 | HOSE | 1 | ||||
| ? | 09480-10100 | CLAMP | 8 | ||||
| ? | 141-06-11220 | CLIP | 9 | ||||
| ? | 01010-81225 | BOLT | 3 | ||||
| ? | 01643-31232 | WASHER | 3 | ||||
| ? | 08034-00519 | BAND | 2 | ||||
| ? | 205-62-53780 | COVER | 1 | ||||
| ? | 08034-00823 | BAND | 2 | ||||
| ? | 207-977-5120 | BRACKET | 1 | ||||
| ? | 01010-81225 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 1 | ||||
| ? | 20T-03-11280 | NIPPLE | 1 | ||||
| ? | 141-06-11220 | CLIP | 1 | ||||
| ? | 01010-81265 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 1 | ||||
| ? | 205-03-71331 | COLLAR | 1 | ||||
| ? | 209-04-19140 | CLIP | 1 | ||||
| ? | VALVE (SEE PG E5-006) | -29 | E5AI6125.002 | ||||
| ? | CONNECTOR (SEE PG 01-014) | -29 | 06AHP400.003 | ||||
| ? | UNIT, COOLING (SEE PG 05-082) | -29 | 13FD6200.007 | ||||
| ? | FRAME, FLOOR (SEE PG 05-042) | -29 | 13AZ6300.003 | ||||
| ? | CLAMP (SEE PG 05-098) | -29 | 13EDP400.002 |
