| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 205-979-6110 | COOLING UNIT | 1 | ||||
| ? | 205-979-7010 | • CASE ASSEMBLY | 1 | ||||
| ? | 205-979-7020 | • CASE ASSEMBLY | 1 | ||||
| ? | 205-979-7030 | • UNIT ASSEMBLY | 1 | ||||
| ? | 205-979-7040 | • PIPE | 1 | ||||
| ? | 205-979-7050 | • EVAPORATOR | 1 | ||||
| ? | 205-979-7060 | • TUBE | 1 | ||||
| ? | 205-979-7070 | • VALVE | 1 | ||||
| ? | 205-979-7080 | • FILTER | 1 | ||||
| ? | 205-979-7090 | • THERMOSTAT | 1 | ||||
| ? | 205-979-7100 | • PACKING | 1 | ||||
| ? | 205-979-7110 | • HOLDER | 1 | ||||
| ? | 205-979-7120 | • VALVE | 1 | ||||
| ? | 205-979-7130 | • CLAMP | 1 | ||||
| ? | 205-979-7140 | • HOSE | 2 | ||||
| ? | 205-979-7150 | • CLAMP | 2 | ||||
| ? | 205-979-7160 | • CLAMP | 1 | ||||
| ? | 205-979-7170 | • PLATE | 1 | ||||
| ? | 205-979-7180 | • BRACKET | 1 | ||||
| ? | 205-979-7190 | • INSULATOR | 1 | ||||
| ? | 205-979-7200 | • FAN | 1 | ||||
| ? | 205-979-7210 | • NUT | 1 | ||||
| ? | 205-979-7220 | • WASHER | 1 | ||||
| ? | 205-979-7230 | • MOTOR ASSEMBLY | 1 | ||||
| ? | 205-979-7250 | • PACKING | 1 | ||||
| ? | 205-979-7240 | • RESISTOR | 1 | ||||
| ? | 205-979-7260 | • PIPE | 1 | ||||
| ? | 205-979-7270 | • WIRE | 1 | ||||
| ? | 205-979-7280 | • CLAMP | 1 | ||||
| ? | 205-979-7290 | • PLATE | 1 | ||||
| ? | 205-979-7300 | • COVER | 1 |
