| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CAB ASSEMBLY (SEE PG 05-048) | -29 | 13CH6300.001 | ||||
| ? | 207-54-00051 | • DOOR ASSEMBLY | 1 | ||||
| ? | 207-54-54120 | • • DOOR | 1 | ||||
| ? | 20Y-54-13113 | • • SASH | 1 | ||||
| ? | 20Y-54-13134 | • • GLASS | 1 | ||||
| ? | 20Y-54-13150 | • • SEAL | 1 | ||||
| ? | 20Y-54-13322 | • • LOCK | 1 | ||||
| ? | 20Y-54-13161 | • • SASH | 1 | ||||
| ? | 20Y-54-13124 | • • GLASS | 1 | ||||
| ? | 20Y-54-14352 | • • LOCK ASSEMBLY | 1 | ||||
| ? | 20Y-54-13171 | • • SEAL | 1 | ||||
| ? | 20Y-54-13180 | • • SEAT | 13 | ||||
| ? | 20Y-54-13190 | • • TRIM | 1 | ||||
| ? | 20Y-54-13450 | • • SEAL | 1 | ||||
| ? | 20Y-54-11692 | • • COVER | 1 | ||||
| ? | 20Y-54-14560 | • • CLIP ASSEMBLY | 4 | ||||
| ? | 20Y-54-13460 | • • SEAL | 3 | ||||
| ? | 20Y-54-13851 | • • SEAL | 1 | ||||
| ? | 20Y-54-14390 | • • GRIP | 1 | ||||
| ? | 20Y-54-14360 | • • BOLT | 2 | ||||
| ? | 20Y-54-11813 | • • STRIKER | 1 | ||||
| ? | 20Y-54-14570 | • • PLATE | 1 | ||||
| ? | 01581-01008 | • • NUT | 2 | ||||
| ? | 01580-11008 | • • NUT | 2 | ||||
| ? | 01643-31032 | • • WASHER | 2 | ||||
| ? | 20Y-54-14180 | • • HINGE ASSEMBLY | 3 | ||||
| ? | 20Y-54-14170 | • • SCREW | 12 | ||||
| ? | 20Y-54-14470 | • • SEAL | 1 | ||||
| ? | • • COVER, DOOR (SEE PG 09-008) | -29 | 02ADP400.004 | ||||
| ? | • • DOOR LOCK ASSEMBLY (SEE PG 05-062) | -29 | 13CM6200.003 | ||||
| ? | 20Y-54-14170 | • SCREW, DOOR MOUNTING | 9 | ||||
| ? | FRAME, CAB (SEE PG 05-048) | -29 | 13CH6300.001 |
