| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-62-61830 | BRACKET | 1 | ||||
| ? | 01010-81660 | BOLT | 6 | ||||
| ? | 01643-31645 | WASHER | 6 | ||||
| ? | 01010-81650 | BOLT | 3 | ||||
| ? | 01643-31645 | WASHER | 3 | ||||
| ? | 20Y-62-22321 | BRACKET | 1 | ||||
| ? | 01010-81230 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 207-06-61441 | BRACKET | 1 | ||||
| ? | 01010-81235 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 20Y-62-22610 | HOSE | 1 | ||||
| ? | 20Y-62-22620 | HOSE | 1 | ||||
| ? | 20Y-62-22630 | HOSE | 1 | ||||
| ? | 20Y-62-22641 | HOSE, 800MM | 1 | ||||
| ? | 207-62-63131 | HOSE ASSEMBLY, 500MM | 1 | ||||
| ? | 207-62-63760 | HOSE ASSEMBLY | 1 | ||||
| ? | 203-62-52260 | • HOSE, 1300MM | 1 | ||||
| ? | 203-62-52350 | • HOSE, 1200MM | 1 | ||||
| ? | 20Y-62-22881 | • HOSE | 1 | ||||
| ? | 20Y-62-22830 | • BAND, WHITE | 2 | ||||
| ? | 20Y-62-22840 | • BAND, BLACK | 2 | ||||
| ? | 08034-00519 | • BAND | 1 | ||||
| ? | 07102-20307 | HOSE | 1 | ||||
| ? | 04434-53212 | CLIP | 1 | ||||
| ? | 195-06-41830 | CLIP | 1 | ||||
| ? | 04434-51812 | CLIP | 1 | ||||
| ? | 01010-81225 | BOLT | 2 | ||||
| ? | 01010-81225 | BOLT | 1 | ||||
| ? | 01643-31232 | WASHER | 3 | ||||
| ? | 08034-00519 | BAND | 1 | ||||
| ? | 08034-00536 | BAND | 1 |
