| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 208-04-00160 | ASSEMBLY, FUEL TANK | 1 | ||||
| ? | (NSS) | • TANK | 1 | ||||
| ? | 20Y-04-21220 | • GAUGE | 1 | ||||
| ? | 07700-50240 | VALVE | 1 | ||||
| ? | 20Y-04-11160 | CAP | 1 | ||||
| ? | 7861-92-5810 | SENSOR | 1 | ||||
| ? | 07000-03050 | O-RING | 1 | ||||
| ? | 01010-50612 | BOLT | 4 | ||||
| ? | 01643-30623 | WASHER | 4 | ||||
| ? | 205-04-71140 | STRAINER | 1 | ||||
| ? | 02700-11206 | ELBOW | 1 | ||||
| ? | 02700-11408 | ELBOW | 1 | ||||
| ? | 01010-51635 | BOLT | 6 | ||||
| ? | 01643-31645 | WASHER | 6 | ||||
| ? | 195-03-11570 | SHIM, 1.0 MM | 2 | ||||
| ? | 154-04-11540 | NIPPLE | 1 | ||||
| ? | 07286-01001 | HOSE | 1 | ||||
| ? | 07281-00197 | CLAMP | 1 |
