| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 723-47-19100 | VALVE ASSEMBLY, CONTROL (SEE PG H-124) | -29 | H0120X40.060 | |||
| ? | 723-40-50400 | • VALVE ASSEMBLY, RELIEF | 2 | ||||
| ? | (NSS) | • • SLEEVE | 1 | ||||
| ? | (NSS) | • • VALVE | 1 | ||||
| ? | (NSS) | • • POPPET | 1 | ||||
| ? | (NSS) | • • SPRING | 1 | ||||
| ? | (NSS) | • • SCREW | 1 | ||||
| ? | (NSS) | • • SPRING | 1 | ||||
| ? | (NSS) | • • PLUG | 1 | ||||
| ? | (NSS) | • • NUT | 1 | ||||
| ? | 700-22-11410 | • • O-RING | 1 | ||||
| ? | 700-80-64220 | • • RING | 1 | ||||
| ? | 07002-02434 | • • O-RING | 1 | ||||
| ? | 07000-02011 | • • O-RING | 1 | ||||
| ? | 723-40-50401 | • VALVE ASSEMBLY, RELIEF | 2 | ||||
| ? | (NSS) | • • SLEEVE | 1 | ||||
| ? | (NSS) | • • SEAT | 1 | ||||
| ? | (NSS) | • • VALVE | 1 | ||||
| ? | (NSS) | • • POPPET | 1 | ||||
| ? | (NSS) | • • SPRING | 1 | ||||
| ? | (NSS) | • • HOLDER | 1 | ||||
| ? | (NSS) | • • SCREW | 1 | ||||
| ? | (NSS) | • • SPRING | 1 | ||||
| ? | (NSS) | • • PLUG | 1 | ||||
| ? | (NSS) | • • NUT | 1 | ||||
| ? | (NSS) | • • NUT | 1 | ||||
| ? | 700-22-11410 | • • O-RING | 1 | ||||
| ? | 700-80-64220 | • • RING | 1 | ||||
| ? | 07002-02434 | • • O-RING | 1 | ||||
| ? | (NSS) | • • O-RING | 1 | ||||
| ? | (NSS) | • • O-RING | 1 | ||||
| ? | (NSS) | • • RING | 1 | ||||
| ? | (NSS) | • • O-RING | 1 |
