| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VALVE ASSEMBLY, CONTROL (SEE PG H-110) | -29 | H0120X40.055 | ||||
| ? | 723-46-00640 | • COVER ASSEMBLY | 1 | ||||
| ? | 723-46-11640 | • • COVER | 1 | ||||
| ? | 706-86-51180 | • • PLUG | 6 | ||||
| ? | 708-21-12520 | • • PLUG | 1 | ||||
| ? | 723-46-00620 | • COVER ASSEMBLY | 1 | ||||
| ? | 723-46-11620 | • • COVER | 1 | ||||
| ? | 706-86-51180 | • • PLUG | 2 | ||||
| ? | 708-21-12520 | • • PLUG | 1 | ||||
| ? | 723-46-15180 | • PLUG | 6 | ||||
| ? | 07002-11823 | • O-RING | 6 | ||||
| ? | 723-46-15100 | • PLUG ASSEMBLY | 1 | ||||
| ? | 723-63-31610 | • • PLUG | 1 | ||||
| ? | 723-46-15170 | • • SCREW | 1 | ||||
| ? | 07002-11423 | • • O-RING | 1 | ||||
| ? | 07000-11007 | • • O-RING | 1 | ||||
| ? | 07001-01007 | • • RING | 1 | ||||
| ? | 723-46-15190 | • VALVE | 2 | ||||
| ? | 723-46-14140 | • SPRING | 2 | ||||
| ? | 708-8E-16160 | • PLUG | 2 | ||||
| ? | 07002-11023 | • O-RING | 2 | ||||
| ? | 709-74-91860 | • PLUG | 1 | ||||
| ? | 07002-12434 | • O-RING | 1 | ||||
| ? | 01010-61490 | • BOLT | 4 | ||||
| ? | 01643-31445 | • WASHER | 10 | ||||
| ? | 01011-51455 | • BOLT | 4 |
