| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 207-970-6130 | FRAME | 1 | ||||
| ? | 205-62-73430 | • SEAT | 2 | ||||
| ? | 01010-81640 | BOLT | 8 | ||||
| ? | 01643-31645 | WASHER | 8 | ||||
| ? | 207-970-6190 | BLOCK | 1 | ||||
| ? | 01011-81205 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 07040-12414 | PLUG | 1 | ||||
| ? | 07002-12434 | O-RING | 1 | ||||
| ? | 706-77-71670 | PLUG | 1 | ||||
| ? | 07002-13034 | O-RING | 1 | ||||
| ? | 207-970-6220 | TUBE | 1 | ||||
| ? | 07000-13032 | O-RING | 1 | ||||
| ? | 01010-81265 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 207-970-5190 | BRACKET | 1 | ||||
| ? | 207-62-52430 | CLAMP | 1 | ||||
| ? | 205-62-73430 | • SEAT | 1 | ||||
| ? | 01010-81270 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 207-970-6201 | VALVE ASSEMBLY | 1 | ||||
| ? | (NSS) | • BLOCK | 1 | ||||
| ? | 207-970-1630 | • SHAFT | 1 | ||||
| ? | 202-970-2210 | • PIN | 1 | ||||
| ? | 07000-13042 | • O-RING | 1 | ||||
| ? | 07001-03042 | • RING | 1 | ||||
| ? | 07000-13048 | • O-RING | 1 | ||||
| ? | 07001-03048 | • RING | 1 | ||||
| ? | 01010-81230 | • BOLT | 1 | ||||
| ? | 01643-31232 | • WASHER | 1 | ||||
| ? | 04065-05220 | • RING | 1 | ||||
| ? | 01011-81205 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 07040-12414 | PLUG | 1 | ||||
| ? | 07002-12434 | O-RING | 1 | ||||
| ? | 706-77-71670 | PLUG | 1 | ||||
| ? | 07002-13034 | O-RING | 1 | ||||
| ? | 207-970-6230 | TUBE | 1 | ||||
| ? | 07000-13032 | O-RING | 1 | ||||
| ? | 01010-81265 | BOLT | 4 | ||||
| ? | 01643-31232 | WASHER | 4 | ||||
| ? | 207-62-52430 | CLAMP | 1 | ||||
| ? | 205-62-73430 | • SEAT | 1 | ||||
| ? | 01010-81230 | BOLT | 2 | ||||
| ? | 01643-31232 | WASHER | 2 | ||||
| ? | 07099-01216 | HOSE | 2 | ||||
| ? | 07000-13038 | O-RING | 4 | ||||
| ? | 07371-51260 | FLANGE | 8 | ||||
| ? | 01010-81245 | BOLT | 16 | ||||
| ? | 01643-31232 | WASHER | 16 |
