| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 600-863-5111 | STARTING MOTOR ASS'Y,(5.5KW) | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028100-5410 | • YOKE ASS'Y | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028200-5250 | • ARMATURE ASS'Y | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949100-3161 | • • BEARING,BALL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949100-5290 | • • BEARING,BALL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949100-3540 | • • BEARING,BALL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028300-6551 | • CLUTCH ASS'Y | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028099-3270 | • • STARTER KIT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028300-6751 | • • CLUTCH ASS'Y | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949100-4500 | • • • BEARING,BALL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949100-1920 | • • • BEARING,BALL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949170-4040 | • • SPRING | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028381-0071 | • • SHAFT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND128401-5621 | • HOUSING | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND153400-6740 | • SWITCH ASS'Y,MAGNETIC | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND128099-5770 | • • KIT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028099-5100 | • • KIT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND053660-0443 | • • PLUNGER | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND053404-0240 | • • GASKET | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND053505-0290 | • • COVER | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND053480-7560 | • • BOLT ASS'Y,TERMINAL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949047-4440 | • • BOLT | 3 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028065-0250 | • • BUSHING,DRAIN | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028510-0880 | • HOLDER ASS'Y,BRUSH | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028520-0011 | • • SPRING,BRUSH | 4 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028501-7711 | • FRAME | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND128961-0010 | • BALL,STEEL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949170-4070 | • SPRING | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028371-3210 | • PINION,STARTER | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028306-0070 | • ROLLER,CLUTCH | 5 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028063-0030 | • RETAINER | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028062-0130 | • COVER | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949042-3680 | • BOLT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND90801-10050 | • O-RING | 3 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949042-3690 | • BOLT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949006-4720 | • SCREW | 3 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949056-4480 | • NUT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028327-0171 | • RETAINER,SNAP | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND90258-10001 | • WASHER,SPRING | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028901-0361 | • SEAL | 2 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028371-3200 | • PINION | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949007-6530 | • SCREW | 4 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028530-1090 | • BRUSH ASS'Y | 2 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028530-1100 | • BRUSH ASS'Y | 2 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND949007-6850 | • SCREW | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028062-5790 | • COVER | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND90170-10061 | • NUT | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND028901-5190 | • SEAL | 1 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
|||
| ? | ND90200-06241 | • WASHER | 3 | SN: 26500006- KIT-FLAG: _- SERIALNO: 26500006- |
