| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | (6204-73-1211) | INJECTION PUMP A. | 1 | SN: 102302- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485. | ||||||
| ? | THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW. | ||||||
| ? | DK105400-5591 | • GOVERNOR ASS'Y | 1 | SN: 102302- |
|||
| ? | THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0465 AND 0466. | ||||||
| ? | DK154000-6300 | • • HOUSING | 1 | SN: 102302- |
|||
| ? | DK029632-5070 | • • O-RING | 1 | SN: 102302- |
|||
| ? | DK154007-2900 | • • PLUG | 1 | SN: 102302- |
|||
| ? | DK154007-0200 | • • ADAPTER | 1 | SN: 102302- |
|||
| ? | DK020018-1840 | • • BOLT | 1 | SN: 102302- |
|||
| ? | DK154350-1900 | • • PLATE | 1 | SN: 102302- |
|||
| ? | DK020006-1440 | • • BOLT | 6 | SN: 102302- |
|||
| ? | DK154010-0100 | • • SCREW | 1 | SN: 102302- |
|||
| ? | DK154011-0100 | • • NUT,LOCK | 1 | SN: 102302- |
|||
| ? | DK154050-1720 | • • LIMITER | 1 | SN: 102302- |
|||
| ? | DK154100-9720 | • • FLYWEIGHT ASS'Y | 1 | SN: 102302- |
|||
| ? | DK029321-2020 | • • WASHER,SPRING | 1 | SN: 102302- |
|||
| ? | DK029231-2030 | • • NUT | 1 | SN: 102302- |
|||
| ? | DK154123-0120 | • • SLEEVE | 1 | SN: 102302- |
|||
| ? | DK029801-0030 | • • • BEARING | 1 | SN: 102302- |
|||
| ? | DK029311-0010 | • • SHIM ? 0.20MM | A/R | SN: 102302- |
|||
| ? | DK029311-0180 | • • SHIM ? 0.30MM | A/R | SN: 102302- |
|||
| ? | DK029311-0190 | • • SHIM ? 0.40MM | A/R | SN: 102302- |
|||
| ? | DK139410-0000 | • • SHIM ? 0.50MM | A/R | SN: 102302- |
|||
| ? | DK029311-0210 | • • SHIM ? 1.00MM | A/R | SN: 102302- |
|||
| ? | DK139410-0100 | • • SHIM ? 1.50MM | A/R | SN: 102302- |
|||
| ? | DK139410-3000 | • • SHIM ? 2.00MM | A/R | SN: 102302- |
|||
| ? | DK139410-3100 | • • SHIM ? 3.00MM | A/R | SN: 102302- |
|||
| ? | DK139410-3200 | • • SHIM ? 4.00MM | A/R | SN: 102302- |
|||
| ? | DK154154-1200 | • • SPRING | 1 | SN: 102302- |
|||
| ? | DK154177-1020 | • • CAPSULE,SPRING | 1 | SN: 102302- |
|||
| ? | DK029201-6010 | • • NUT | 1 | SN: 102302- |
|||
| ? | DK154210-0920 | • • GUIDE LEVER ASS'Y | 1 | SN: 102302- |
|||
| ? | DK154230-3920 | • • LINK | 1 | SN: 102302- |
|||
| ? | DK016010-0540 | • • RING,SNAP | 1 | SN: 102302- |
|||
| ? | DK154236-4100 | • • LEVER,TENSION | 1 | SN: 102302- |
|||
| ? | DK154350-7700 | • • GASKET | 1 | SN: 102302- |
