| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AXLE ASSEMBLY, REAR (SEE FIG. F4500-51A0 ) | SN: A76001-- |
F4500-51A0 | ||||
| ? | 418-23-31231 | • COUPLING | 1 | SN: A76001-- |
|||
| ? | 418-22-21310 | • PROTECTOR | 1 | SN: A76001-- |
|||
| ? | 418-23-31201 | • PINION ASSEMBLY | 1 | SN: A76001-- |
|||
| ? | (NSS) | • • PINION | 1 | SN: A76001-- |
|||
| ? | (NSS) | • • GEAR, BEVEL | 1 | SN: A76001-- |
|||
| ? | 418-22-11810 | • BEARING | 1 | SN: A76001-- |
|||
| ? | 418-23-31131 | • CAGE | 1 | SN: A76001-- |
|||
| ? | 418-22-31861 | • SPACER | 1 | SN: A76001-- |
|||
| ? | 419-22-11820 | • BEARING | 1 | SN: A76001-- |
|||
| ? | 418-22-21330 | • SEAL, OIL | 1 | SN: A76001-- |
|||
| ? | 417-15-13770 | • HOLDER | 1 | SN: A76001-- |
|||
| ? | 01011-61615 | • BOLT | 1 | SN: A76001-- |
|||
| ? | 07000-13042 | • O-RING | 1 | SN: A76001-- |
|||
| ? | 417-22-11361 | • SHIM, 0.05 MM | 2 | SN: A76001-- |
|||
| ? | 417-22-11371 | • SHIM, 0.20 MM | 2 | SN: A76001-- |
|||
| ? | 417-22-11381 | • SHIM, 0.30 MM | 2 | SN: A76001-- |
|||
| ? | 417-22-11391 | • SHIM, 0.80 MM | 1 | SN: A76001-- |
|||
| ? | 01010-E1235 | • BOLT | 13 | SN: A76001-- |
|||
| ? | 01643-31232 | • WASHER | 13 | SN: A76001-- |
|||
| ? | 07000-15160 | • O-RING | 1 | SN: A76001-- |
|||
| ? | 418-23-31501 | • CASE ASSEMBLY | 1 | SN: A76001-- |
|||
| ? | (NSS) | • • CASE | 1 | SN: A76001-- |
|||
| ? | (NSS) | • • CASE | 1 | SN: A76001-- |
|||
| ? | 417-22-11432 | • GEAR | 2 | SN: A76001-- |
|||
| ? | 417-22-11420 | • PINION | 4 | SN: A76001-- |
|||
| ? | 418-23-31410 | • SPIDER | 1 | SN: A76001-- |
|||
| ? | 418-23-31460 | • WASHER | 2 | SN: A76001-- |
|||
| ? | 418-23-31550 | • WASHER | 4 | SN: A76001-- |
|||
| ? | 01010-61695 | • BOLT | 12 | SN: A76001-- |
|||
| ? | 01010-61645 | • BOLT | 4 | SN: A76001-- |
|||
| ? | 417-22-12840 | • BEARING | 2 | SN: A76001-- |
|||
| ? | 418-23-33111 | • HOUSING | 1 | SN: A76001-- |
