| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 07260-22650 | HOSE | 1 | SN: A76001-- |
|||
| ? | 07289-00045 | CLAMP | 2 | SN: A76001-- |
|||
| ? | 418-18-32530 | ELBOW | 1 | SN: A76001-- |
|||
| ? | 07000-13038 | O-RING | 1 | SN: A76001-- |
|||
| ? | 418-18-32321 | TEE | 1 | SN: A76001-- |
|||
| ? | 07000-12018 | O-RING | 1 | SN: A76001-- |
|||
| ? | 02896-11015 | O-RING | 1 | SN: A76001-- |
|||
| ? | 418-18-32361 | HOSE, 550 MM | 1 | SN: A76001-- |
|||
| ? | 417-18-32190 | NIPPLE | 1 | SN: A76001-- |
|||
| ? | 07000-12018 | O-RING | 1 | SN: A76001-- |
|||
| ? | 02782-10520 | ELBOW | 1 | SN: A76001-- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: A76001-- |
|||
| ? | 02896-11015 | O-RING | 3 | SN: A76001-- |
|||
| ? | 418-18-32272 | HOSE, 460 MM | 1 | SN: A76001-- |
|||
| ? | 02782-10516 | ELBOW | 1 | SN: A76001-- |
|||
| ? | 07002-12034 | O-RING | 1 | SN: A76001-- |
|||
| ? | 418-18-32342 | ELBOW | 1 | SN: A76001-- |
|||
| ? | 07000-12018 | O-RING | 2 | SN: A76001-- |
|||
| ? | 02896-11015 | O-RING | 2 | SN: A76001-- |
|||
| ? | 418-18-42250 | HOSE, 1120 MM | 1 | SN: A76001-- |
|||
| ? | 418-18-42560 | HOSE, 1470 MM | 1 | SN: A76001-- |
|||
| ? | 08210-01803 | SPIRAL TUBE | 2 | SN: A76001-- |
|||
| ? | 08210-01802 | SPIRAL TUBE | 1 | SN: A76001-- |
|||
| ? | 417-18-32330 | ELBOW | 1 | SN: A76001-- |
|||
| ? | 07000-13024 | O-RING | 1 | SN: A76001-- |
|||
| ? | 02896-11018 | O-RING | 2 | SN: A76001-- |
|||
| ? | 418-18-42380 | HOSE, 710 MM | 1 | SN: A76001-- |
|||
| ? | 08210-01803 | • SPIRAL TUBE | 1 | SN: A76001-- |
|||
| ? | 02783-10628 | ELBOW | 1 | SN: A76001-- |
|||
| ? | 07002-12434 | O-RING | 1 | SN: A76001-- |
|||
| ? | 04434-52312 | CLIP | 2 | SN: A76001-- |
|||
| ? | 01010-81020 | BOLT | 1 | SN: A76001-- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: A76001-- |
|||
| ? | 01011-E1005 | BOLT | 1 | SN: A76001-- |
|||
| ? | 01643-31032 | WASHER | 1 | SN: A76001-- |
|||
| ? | 417-18-32190 | NIPPLE | 1 | SN: A76001-- |
|||
| ? | 04434-52312 | CLIP | 1 | SN: A76001-- |
|||
| ? | 6150-71-7130 | COLLAR | 1 | SN: A76001-- |
|||
| ? | 7861-93-3320 | SENSOR, OIL TEMPERATURE | 1 | SN: A76001-- |
|||
| ? | 418-18-44130 | BRACKET | 1 | SN: A76001-- |
|||
| ? | 01010-81020 | BOLT | 4 | SN: A76001-- |
|||
| ? | 01643-31032 | WASHER | 4 | SN: A76001-- |
|||
| ? | 417-18-34110 | FILTER ASSEMBLY | 1 | SN: A76001-- |
|||
| ? | 417-18-34130 | • CARTRIDGE | 1 | SN: A76001-- |
|||
| ? | 11Y-62-12340 | ELBOW | 2 | SN: A76001-- |
|||
| ? | 07002-13334 | O-RING | 2 | SN: A76001-- |
|||
| ? | 02896-11018 | O-RING | 2 | SN: A76001-- |
|||
| ? | 418-18-42390 | HOSE, 600 MM | 1 | SN: A76001-- |
|||
| ? | 08210-01801 | • SPIRAL TUBE | 1 | SN: A76001-- |
