| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP, VARIABLE (SEE FIG. F2430-02A0 ) | SN: A76001-- |
F2430-02A0 | ||||
| ? | UC4704348567 | • VALVE | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704361673 | • • PLUG | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704496229 | • • SCREW | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704358998 | • • PISTON | 1 | SN: A76001-- |
F1 | ||
| ? | UC1720103369 | • • SPRING SEAT | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704407659 | • • SPRING | 1 | SN: A76001-- |
F1 | ||
| ? | UC1300170008 | • • O-RING | 1 | SN: A76001-- |
|||
| ? | UC1701532717 | • • NUT | 1 | SN: A76001-- |
F1 | ||
| ? | 9 | ||||||
| ? | F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY. | 10 |
