| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PUMP, VARIABLE (SEE FIG. F2430-02A0 ) | SN: A76001-- |
F2430-02A0 | ||||
| ? | UC4100516369 | • ROTARY GROUP | 1 | SN: A76001-- |
F1 | ||
| ? | UC4100663833 | • • CYLINDER BLOCK | 1 | SN: A76001-- |
F1 | ||
| ? | UC4704145157 | • • PISTON | 9 | SN: A76001-- |
F1 | ||
| ? | UC1709217287 | • • SPRING | 1 | SN: A76001-- |
|||
| ? | UC1709222555 | • • HANGER | 1 | SN: A76001-- |
|||
| ? | UC1704498106 | • • GUIDE | 1 | SN: A76001-- |
|||
| ? | UC1099215509 | • • SHAFT | 1 | SN: A76001-- |
|||
| ? | UC1704179593 | • • PIN | 2 | SN: A76001-- |
|||
| ? | UC1709217296 | • • RETAINER | 1 | SN: A76001-- |
F1 | ||
| ? | UC1709217306 | • • GUIDE | 1 | SN: A76001-- |
F1 | ||
| ? | UC1020665932 | • • BEARING | 1 | SN: A76001-- |
|||
| ? | UC1704498858 | • • SHIM, 3.0 MM | 2 | SN: A76001-- |
|||
| ? | UC1704356497 | • • SPRING | 1 | SN: A76001-- |
|||
| ? | UC1701531044 | • • BEARING | 1 | SN: A76001-- |
|||
| ? | UC1708301657 | • • BEARING | 1 | SN: A76001-- |
|||
| ? | UC1302133001 | • • RING | 1 | SN: A76001-- |
|||
| ? | UC1726000019 | • • WASHER | 2 | SN: A76001-- |
|||
| ? | UC1026018204 | • • RING, SEAL | 1 | SN: A76001-- |
|||
| ? | UC1700845562 | • • WASHER | 1 | SN: A76001-- |
|||
| ? | UC1704329835 | • • SHIM, 1.2 MM | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704329844 | • • SHIM, 1.0 MM | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704329853 | • • SHIM, 0.8 MM | 1 | SN: A76001-- |
F1 | ||
| ? | UC1704329862 | • • SHIM, 0.6 MM | 1 | SN: A76001-- |
F1 | ||
| ? | 24 | ||||||
| ? | F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY. | 25 |
