| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TRANSFER ASSEMBLY (SEE FIG. F2420-51A0) | SN: A76001-- |
F2420-51A0 | ||||
| ? | TRANSFER ASSEMBLY (SEE FIG. F2420-51A0) | SN: A76001-- |
F2420-51A0 | ||||
| ? | (NSS) | • TRANSFER SUBASSEMBLY | 1 | SN: A76001-- |
|||
| ? | 418-17-31105 | • CASE ASSEMBLY | 1 | SN: A76001-- |
|||
| ? | (NSS) | • • CASE, FRONT | 1 | SN: A76001-- |
|||
| ? | (NSS) | • • CASE, REAR | 1 | SN: A76001-- |
|||
| ? | 01010-81235 | • BOLT | 20 | SN: A76001-- |
|||
| ? | 04020-01228 | • PIN | 2 | SN: A76001-- |
|||
| ? | 07043-A0211 | • PLUG | 2 | SN: A76001-- |
|||
| ? | 07044-12412 | • PLUG | 1 | SN: A76001-- |
|||
| ? | 07002-12434 | • O-RING | 1 | SN: A76001-- |
|||
| ? | 07030-00252 | • BREATHER | 1 | SN: A76001-- |
|||
| ? | 418-17-31132 | • CAGE | 1 | SN: A76001-- |
|||
| ? | 01010-81235 | • BOLT | 6 | SN: A76001-- |
|||
| ? | 07000-75130 | • O-RING | 1 | SN: A76001-- |
|||
| ? | 09608-05080 | • PLATE, NAME | 1 | SN: A76001-- |
|||
| ? | 04418-13060 | • SCREW | 4 | SN: A76001-- |
|||
| ? | 07049-01215 | • PLUG | 9 | SN: A76001-- |
|||
| ? | 07049-01620 | • PLUG | 1 | SN: A76001-- |
|||
| ? | HOUSING (SEE FIG. F2420-55A0 ) | SN: A76001-- |
F2420-55A0 |
