| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 141 802 | TEE, ADJUSTABLE | 1 | ||||
| ? | 296 247 | • O-RING | 1 | ||||
| ? | 728 155 C1 | SENDING UNIT, CONVERTER OIL TEMPERATURE | 1 | ||||
| ? | 131 542 | BUSHING, REDUCER | 1 | ||||
| ? | 158 982 | SWITCH, CONVERTER OIL TEMPERATURE | 1 | ||||
| ? | 1137 360 C2 | SWITCH, ENGINE WATER TEMPERATURE | 1 | ||||
| ? | 1216 162 H1 | SENDING UNIT, ENGINE WATER TEMPERATURE | 1 | ||||
| ? | 677 161 R93 | SENDING UNIT, ENGINE OIL PRESSURE | 1 | ||||
| ? | 593 762 R1 | SCREW, SELF-TAPPING | 5 | ||||
| ? | 85 065 | WASHER, LOCK | 5 | ||||
| ? | 55 845 A | SENDING UNIT, FUEL GAUGE | 1 | ||||
| ? | 29 362 | GASKET | 1 | ||||
| ? | 882 665 C1 | SWITCH, ENGINE OIL PRESSURE | 1 | ||||
| ? | 9409 935 | TEE | A/R | ||||
| ? | 443 976 | ADAPTOR | A/R | ||||
| ? | 163 109 H45 | SWITCH, CLUTCH PRESSURE | 1 | ||||
| ? | 161 849 | COUPLING, QUICK DISCONNECT | 1 | ||||
| ? | 162 144 | CAP, DUST | 1 | ||||
| ? | 1430 227 H1 | SWITCH, HIGH PRESSURE | 1 | F1 | |||
| ? | 114 951 | SWITCH, BRAKE PRESSURE | 2 | ||||
| ? | |||||||
| ? | F1 - 2 REQUIRED WITH AWD | ||||||
| ? |
