Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
|
ALTERNATOR (SEE PG 08-026) |
-29 |
|
08-026 |
|
|
? |
1216 162 H1 |
SENDING UNIT, ENGINE WATER TEMPERATURE |
1 |
|
|
|
|
? |
1285 368 H91 |
HARNESS, ENGINE WIRING |
1 |
|
|
|
|
? |
299 407 C1 |
CLAMP, CABLE |
1 |
|
|
|
|
? |
299 614 C1 |
CLAMP, CABLE |
3 |
|
|
|
|
? |
931 833 R1 |
BOLT |
3 |
|
|
|
|
? |
30 328 R1 |
WASHER, FLAT |
3 |
|
|
|
|
? |
|
TEE, ADJUSTABLE (SEE PG 06-006) |
-29 |
|
06-006 |
|
|
? |
|
MOTOR, CRANKING (SEE PG 08-020) |
-29 |
|
08-020 |
|
|
? |
|
SENDING UNITS, TRANSMISSION (SEE PG 08-048) |
-29 |
|
08-048 |
|
|
? |
|
HARNESS, REAR LIGHT (SEE PG 08-004) |
-29 |
|
08-004 |
|
|
? |
141 453 H1 |
CLAMP, CABLE |
2 |
|
|
|
|
? |
30 328 R1 |
WASHER, FLAT |
2 |
|
|
|
|
? |
1282 296 H94 |
HARNESS, MAIN WIRING |
1 |
|
|
|
|
? |
130 096 |
CLAMP, CABLE |
1 |
|
|
|
|
? |
25 534 R1 |
WASHER, FLAT |
1 |
|
|
|
|
? |
25 522 R1 |
NUT, HEX |
1 |
|
|
|
|
? |
|
FILTER, CONVERTER OIL (SEE PG 07-014) |
-29 |
|
07-014 |
|
|
? |
299 404 C1 |
CLAMP, CABLE |
1 |
|
|
|
|
? |
1207 387 H1 |
SWITCH, MAGNETIC |
1 |
|
|
|
|
? |
28 488 R1 |
BOLT |
2 |
|
|
|
|
? |
120 392 |
WASHER, FLAT |
2 |
|
|
|
|
? |
25 402 R1 |
NUT, HEX |
2 |
|
|
|
|
? |
1259 560 H1 |
DIODE |
1 |
|
|
|
|
? |
|
SENDING UNITS, ENGINE OIL PRESSURE (SEE PG 08-048) |
-29 |
|
08-048 |
|
|
? |
1137 360 C2 |
SWITCH, ENGINE WATER TEMPERATURE |
1 |
|
|
|
|
? |
27 834 R1 |
CLAMP, CABLE |
1 |
|
|
|
|
? |
25 534 R1 |
WASHER, FLAT |
1 |
|
|
|
|
? |
25 522 R1 |
NUT, HEX |
1 |
|
|
|
|
? |
|
HORN INSTALLATION (SEE PG 08-044) |
-29 |
|
08-044 |
|
|
? |
299 399 C1 |
CLAMP, CABLE |
1 |
|
|
|
|
? |
37 467 |
STUD, WELD |
1 |
|
|
|
|
? |
25 532 R1 |
WASHER, FLAT |
1 |
|
|
|
|
? |
25 519 R1 |
NUT, HEX |
1 |
|
|
|
|
? |
|
SENDING UNIT, ARTICULATION (SEE PG 08-050) |
-29 |
|
08-050 |
|
