| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | BODY, VALVE (NOT SERVICED SEPARATELY) | 1 | |||||
| ? | 07042-20108 | PLUG | 7 | ||||
| ? | 07043-70108 | PLUG | 1 | ||||
| ? | 711-35-46630 | SPOOL | 2 | ||||
| ? | 711-35-46651 | PISTON | 2 | ||||
| ? | 711-35-46660 | VALVE | 2 | ||||
| ? | 711-35-26690 | SPRING | 2 | ||||
| ? | 711-28-46761 | SPRING | 1 | ||||
| ? | 561-13-46760 | SPRING | 1 | ||||
| ? | 125-15-36480 | SHIM - 0.5 MM | 3 | ||||
| ? | 711-35-26821 | SPOOL | 1 | ||||
| ? | 198-15-15760 | VALVE | 1 | ||||
| ? | 561-13-46850 | PISTON | 1 | ||||
| ? | 198-15-15770 | SPRING | 1 | ||||
| ? | 561-13-46830 | SPRING | 1 | ||||
| ? | 561-13-46670 | PISTON | 1 | ||||
| ? | 711-20-16730 | RING | 1 | ||||
| ? | 561-13-46840 | PISTON | 1 | ||||
| ? | 01643-51032 | WASHER | 12 | ||||
| ? | 711-20-16720 | COVER | 2 | ||||
| ? | 711-20-16740 | PLATE | 2 | ||||
| ? | 711-40-16760 | COVER | 1 | ||||
| ? | 01010-81045 | CAPSCREW | 4 | ||||
| ? | 711-35-46780 | COVER | 1 | ||||
| ? | 01010-81030 | CAPSCREW | 8 | ||||
| ? | 07000-63038 | O-RING (1) | 6 | ||||
| ? | 07000-62010 | O-RING (1) | 3 | ||||
| ? | 561-13-05022 | NOTE: (1) INCLUDED IN 561-13-05022 TORQUE | |||||
| ? | CONVERTER SERVICE KIT. | ||||||
| ? | (INCLUDED IN 561-13-00110 TORQUE CONVERTER | ||||||
| ? | ASSEMBLY. COMPLETE TORQUE CONVERTER/TRANSMISSION | ||||||
| ? | ASSEMBLY IS 561-14-51050.) |
