| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 565-06-11641 | CABLE, GROUND | 2 | ||||
| ? | 01010-81016 | CAPSCREW | 31 | ||||
| ? | 01010-81216 | CAPSCREW | 1 | ||||
| ? | 01643-31032 | FLAT WASHER - M10 | 38 | ||||
| ? | 01643-31232 | FLAT WASHER - M12 | 1 | ||||
| ? | 08036-01414 | CLAMP, VINYL | 12 | ||||
| ? | 01220-70612 | SCREW | 4 | ||||
| ? | 01642-40608 | WASHER | 4 | ||||
| ? | 569-54-61850 | COVER | 1 | ||||
| ? | 569-54-61840 | PLATE | 1 | ||||
| ? | 01011-51000 | CAPSCREW | 4 | ||||
| ? | 6130-124571 | SPACER | 4 | ||||
| ? | 23S-06-13221 | LIGHT, HEAD | 2 | ||||
| ? | 421-06-13150 | BRACKET ASSEMBLY | 2 | ||||
| ? | 01580-10504 | NUT | 4 | ||||
| ? | 01643-30623 | WASHER | 9 | ||||
| ? | 01220-40512 | SCREW | 4 | ||||
| ? | 421-06-13401 | LAMP ASSEMBLY, R.H. TURN SIGNAL | 1 | ||||
| ? | 421-06-13310 | • BULB - 10/4W | 1 | ||||
| ? | 22W-06-12320 | • LENS | 1 | ||||
| ? | 08105-12420 | • BULB - 26W | 2 | ||||
| ? | 08053-01512 | CLIP, CONNECTOR | 1 | ||||
| ? | 561-06-64330 | PLUG, CONNECTOR | 1 | ||||
| ? | 08036-01214 | CLAMP, VINYL | 2 | ||||
| ? | 424-09-12530 | BOOT, BATTERY TERMINAL (+) | 4 | ||||
| ? | 08028-45150 | CABLE, BATTERY (JUMPER + TO +) | 1 | ||||
| ? | 424-09-12540 | BOOT, BATTERY TERMINAL (-) | 4 | ||||
| ? | 08028-45020 | CABLE, BATTERY (JUMPER + TO -) | 2 | ||||
| ? | 08028-45100 | CABLE, BATTERY (JUMPER - TO -) | 2 | ||||
| ? | 08028-45080 | CABLE, BATTERY GROUND | 1 | ||||
| ? | 08036-02514 | CLAMP, VINYL | 13 | ||||
| ? | 566-06-41290 | INSULATOR, CLAMP | 6 | ||||
| ? | 561-06-63532 | HARNESS, R.H. DECK | 1 | ||||
| ? | 561-06-63740 | PLUG, CONNECTOR | 1 | ||||
| ? | 08053-00910 | CLIP, CONNECTOR | 1 | ||||
| ? | 08037-03614 | GROMMET | 1 | ||||
| ? | 08028-45050 | CABLE, BATTERY | 2 | ||||
| ? | 08088-40000 | RELAY (BATTERY & EMERGENCY STRG) | 4 | ||||
| ? | 01010-80830 | CAPSCREW | 8 | ||||
| ? | 01643-30823 | FLAT WASHER - M8 | 8 | ||||
| ? | 08038-00035 | CAP, TERMINAL | 8 | ||||
| ? | 08028-45011 | CABLE (JUMPER) | 4 | ||||
| ? | 561-06-61850 | BRACKET | 1 | ||||
| ? | 01010-81020 | CAPSCREW | 5 | ||||
| ? | 561-06-61471 | CABLE | 1 | ||||
| ? | 08037-02512 | GROMMET | 5 | ||||
| ? | 421-06-11440 | CIRCUIT BREAKER - 80 AMP | 1 | ||||
| ? | 01010-80616 | CAPSCREW | 2 | ||||
| ? | 01023-20616 | SCREW | 1 | ||||
| ? | 566-06-6A220 | FUSE UNIT | 1 | ||||
| ? | 42A-06-16140 | • FUSE - 30 AMP | 1 | ||||
| ? | 08037-02512 | GROMMET | 2 | ||||
| ? | 08053-00912 | CLIP, CONNECTOR | 2 | ||||
| ? | 561-06-63381 | CLAMP | 3 | ||||
| ? | 561-06-63470 | BLOCK, RUBBER (2 PER CLAMP) | 6 | ||||
| ? | 01010-80640 | CAPSCREW | 3 |
