| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 561-54-64440 | MOTOR, WIPER | 1 | ||||
| ? | 561-54-64410 | ARM, WIPER | 1 | ||||
| ? | 561-54-64420 | BLADE | 1 | ||||
| ? | 421-54-15430 | NOZZLE | 1 | ||||
| ? | 561-54-64430 | HOSE | 1 | ||||
| ? | 421-54-15520 | CLIP | 3 | ||||
| ? | 581-54-23880 | LAMP, DOME | 1 | ||||
| ? | 581-54-23890 | • LENS | 1 | ||||
| ? | 08116-02410 | • BULB | 2 | ||||
| ? | 561-06-61350 | CABLE | 1 | ||||
| ? | 561-54-64460 | GROMMET | 5 | ||||
| ? | 561-54-64470 | GROMMET | 3 | ||||
| ? | 561-54-64480 | GROMMET | 1 | ||||
| ? | 01220-40616 | SCREW | 4 | ||||
| ? | 01220-40520 | SCREW | 2 | ||||
| ? | 01602-20619 | WASHER, SPRING | 4 | ||||
| ? | 01641-20508 | WASHER | 4 | ||||
| ? | 01641-20608 | WASHER | 2 | ||||
| ? | 561-54-64450 | GROMMET | 2 | ||||
| ? | 561-54-62191 | VISOR, SUN | 1 | ||||
| ? | 01225-40520 | SCREW | 8 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | 561-54-64680 | PLATE | 1 | ||||
| ? | 561-54-62980 | PLATE | 1 | ||||
| ? | 561-54-62990 | CATCHER | 1 | ||||
| ? | 01220-40306 | SCREW | 2 | ||||
| ? | 01220-40512 | SCREW | 2 | ||||
| ? | 01641-20305 | WASHER | 2 | ||||
| ? | 01641-20508 | WASHER | 2 |
