| Наименование | Страница | Код страницы |
|---|---|---|
| FIG. M5100-01A0 TRIM GROUP | M-002 | M5100-01A0 |
| FIG. M5100-01A0 TRIM GROUP | M-002 | M5100-01A0 |
| FIG. M5110-01A0 HOOD TOP - S/N 210567 AND DOWN | M-004 | M5110-01A0 |
| FIG. M5110-01A1 HOOD TOP - S/N 210568 AND UP | M-006 | M5110-01A1 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 1433 107 H91 | HOOD SIDE ASSEMBLY - L.H. | 1 | ||||
| ? | 1433 102 H91 | • HOOD SIDE WELDMENT | 1 | ||||
| ? | 1246 804 H1 | • LOCK, ENGINE PANEL | 1 | F1 | |||
| ? | 25 222 R1 | • BOLT | 4 | ||||
| ? | 1436 959 H1 | • SHIM | A/R | ||||
| ? | 140 359 | • HANDLE, ENGINE PANEL | 1 | ||||
| ? | 593 762 R1 | • SCREW, SELF-TAPPING | 3 | ||||
| ? | 1432 711 H1 | PROP, DOOR - GAS SPRING | 2 | ||||
| ? | 120 214 | WASHER, LOCK | 4 | ||||
| ? | 25 520 R1 | NUT, HEX | 4 | ||||
| ? | 25 519 R1 | NUT | 10 | ||||
| ? | 1431 479 H1 | STRIP, SEAL - 18.75 IN. | 2 | ||||
| ? | 1433 105 H91 | HOOD SIDE ASSEMBLY - R.H. | 1 | ||||
| ? | 1433 100 H91 | • HOOD SIDE WELDMENT | 1 | ||||
| ? | 140 359 | • HANDLE, ENGINE PANEL | 1 | ||||
| ? | 593 762 R1 | • SCREW, SELF-TAPPING | 3 | ||||
| ? | 1246 804 H1 | • LOCK, ENGINE PANEL | 1 | ||||
| ? | 25 222 R1 | • BOLT | 4 | ||||
| ? | 1436 959 H1 | • SHIM | A/R | ||||
| ? | 25 222 R1 | BOLT | 10 | ||||
| ? | 25 532 R1 | WASHER, FLAT | 20 | ||||
| ? | OR | ||||||
| ? | 1431 479 H1 | STRIP, SEAL - 26.5 IN. | 2 | ||||
| ? | |||||||
| ? | F1 TO SECURE THE DOOR, USE A PADLOCK P/N 650 382 C92 AND KEYS P/N 1311 216 H1. | ||||||
| ? |
