Номер на схеме	Каталожный номер	Название	Количество
?	1436 943 H91	SHELL WELDMENT - REAR	1
?	1436 942 H1	• PLATE, COVER - HYDRAULIC OIL FILL	1
?	1434 616 H1	• PLATE, COVER - FUEL FILL	1	F1
?	1279 452 H1	• HANDLE, GRAB - L.H.	1
?	1250 695 H1	• SUPPORT - L.H.	1
?	1279 452 H1	HANDLE, GRAB - R.H. - OPTIONAL	1
?	1250 695 H1	SUPPORT - R.H. - OPTIONAL	1
?	120 382	WASHER, LOCK	24
?	120 394	WASHER, PLAIN	24
?	24 842 R1	BOLT	3
?	162 033	GRILL WELDMENT - REAR	1
?	24 840 R1	BOLT	1
?	120 382	WASHER, LOCK	1
?	120 394	WASHER, FLAT	3
?	21 622 R1	NUT, LOCK	2
?	24 841 R1	BOLT	13
?	140 483 H	BOLT	8
?	140 483 H	BOLT	10
?	120 382	WASHER, LOCK	10
?	120 394	WASHER, FLAT	10
?	25 522 R1	NUT, HEX	10
?	149 865	STRIP, RADIATOR SEAL	2
?	149 864	SEAL, RADIATOR	2
?	140 483 H	BOLT	2
?	1435 185 H1	BRACKET, RADIATOR SUPPORT	1
?	25 553 R1	WASHER, FLAT	4
?	21 622 R1	NUT, LOCK	2
?	1435 184 H1	BAR, SHOCK MOUNT	1
?	24 840 R1	BOLT	2
?	120 382	WASHER, LOCK	2
?	25 553 R1	WASHER, FLAT	2
?	26 319 R1	BOLT, LOCK	1
?	113 977	WASHER, SPECIAL	1
?	124 813	MOUNT, RUBBER	1
?	149 134	PLATE, COVER	1
?	140 483 H	BOLT	3
?	120 382	WASHER	3
?	1436 946 H91	SHELL WELDMENT - FRONT	1
?	1436 942 H1	• PLATE, COVER - RADIATOR FILL	1	F1
?	1436 628 H91	GRILL WELDMENT, REMOVABLE - R.H.	1
?	1436 629 H91	GRILL WELDMENT, REMOVABLE - L.H.	1
?	24 840 R1	BOLT	8
?	120 382	WASHER, LOCK	8
?	120 394	WASHER, FLAT	8
?	1436 924 H91	PANEL, ENGINE	1
?	1436 920 H91	TRAY, BATTERY	1
?
?		F1 TO SECURE THE COVER, USE PADLOCK P/N 650 382 C92 AND KEYS P/N 1311 216 H1.
?
