| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CONTROL VALVE ASSEMBLY - FLOAT (SEE FIG. H0970-6230) | SN: A40001-- |
H0970-6230 | ||||
| ? | 723-11-19620 | • PLUG | 1 | SN: A40001-- |
|||
| ? | 709-32-11840 | • O-RING | 1 | SN: A40001-- |
|||
| ? | 07002-12034 | • O-RING | 1 | SN: A40001-- |
|||
| ? | 723-10-80200 | • VALVE ASSEMBLY | 2 | SN: A40001-- |
|||
| ? | (NSS) | • • VALVE | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • O-RING | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • GASKET | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • HOLDER - VALVE WITH CASE | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A40001-- |
|||
| ? | 723-10-18600 | • VALVE ASSEMBLY | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • HOLDER - VALVE WITH CASE | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • ORIFICE DISC | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • SCREW | 1 | SN: A40001-- |
|||
| ? | 07000-12011 | • • O-RING | 2 | SN: A40001-- |
|||
| ? | 01583-11408 | • • NUT | 1 | SN: A40001-- |
|||
| ? | 700-22-11410 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | 07002-12434 | • • O-RING | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • RING | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • VALVE | 1 | SN: A40001-- |
|||
| ? | (NSS) | • • SPRING | 1 | SN: A40001-- |
